Power Transformer Trainer

Price 1000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Power Transformer Trainer Specification

Display Type
Analog Voltmeters and Ammeters

Features
Short circuit and open circuit testing, transformer winding demonstration, clearly labeled connections, onboard protection, educational graphics, portable case.

Components
Single-phase power transformer, demonstration panel, circuit breakers, measuring sockets, fuse, indicator lamps, terminal posts.

Output
Various taps for stepped output voltages (typically 3V/6V/9V/12V AC), accessible via terminals.

Input
230V AC Input

Power Supply
230V, 50 Hz AC mains

Power Source
AC Mains

Usage
Laboratory, Educational Training

Product Type
Teaching Equipment

Application
Transformer Trainer

Rated Voltage
230V AC

Supply Voltage
230V AC

Size
Tabletop

Dimension (L*W*H)
Approx. 600mm x 400mm x 200mm

Function
Demonstrates working of a power transformer, winding connections, and voltage transformation.

Color
White/Blue with printed diagrams.

Weight
Approx. 12 kg

Thickness
2-3 mm panel thickness

Current Rating
Up to 5A

Capacity
Variable up to 2 kVA (as per configuration)

Frequency
50 Hz

Power Transformer Trainer Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID), Cash Advance (CA), Letter of Credit (L/C), Telegraphic Transfer (T/T), Cheque

Supply Ability
Unit

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Eastern Europe, Western Europe, Middle East, Asia, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Power Transformer Trainer

Power Transformer Trainer

Edutek Instrumentation are the Best Manufacturer and Exporter Power Transformer Trainer Company in India Export India and other Country of Power Transformer Trainer. Transformer Trainer demonstrates the principles of Lenzs first and second laws as applied to transformers. Typical material covered includes efficiency, ratios, vectors, open circuit test and short circuit test.

1 x three phase voltage and current.
Low voltage power supplies: 0-30 V DC and 0-30 V AC.
Transformers: 2 x Low voltage single phase 150 VA (one Step Up 30/240 V and Other Step Down 240/30 V.
1 x line power 5 KVA three phase star delta Dy 11-reduces the incoming supply down.
1 x line receive 3 KVA three phase star-delta Dy 11 with star point link to earth 220 V/110 V three phase.
Includes tap section on its primary windings of 10%, 7.5% , 5%, 2.5%, and 0%. 220 V Star connected Resistive, Inductive and capacitive. 110 V Delta connected Resistive.

Comprehensive Training Solution

This transformer trainer equips students with practical knowledge of transformer operation, short and open circuit testing, and winding demonstrations. Features such as clearly labeled connections, analog meters, and onboard protection, ensure students learn safely and efficiently. Its robust construction and desktop mounting provide reliability and flexibility during laboratory sessions.

Safe and Durable Design

Manufactured with powder-coated metal panels and a sturdy enclosure, the trainer guarantees long-term durability. The incorporation of overload protection devices and compliance with IS:2026 ensures genuine safety during experiments. All terminals are color-coded and easily accessible, supporting intuitive and error-free handling for users.

Ideal for Educational Laboratories

Designed for engineering and vocational institutes, the trainer simplifies transformer principles with printed educational diagrams and user-friendly components. Its variable taps enable demonstrations of different output voltages, while supplied accessories like patch cords and a manual support seamless learning and setup.

FAQs of Power Transformer Trainer:

Q: How does the Power Transformer Trainer demonstrate transformer working principles?

A: The trainer utilizes a single-phase core-type transformer with clear, color-coded terminals, laminated diagrams, and analog meters to support the demonstration of winding connections and voltage transformation. Hands-on testing of short and open circuits is conducted via accessible test points and measuring sockets.

Q: What safety standards does this transformer trainer comply with?

A: The trainer is manufactured as per IS:2026 safety standards. It features onboard protection elements such as overload relays, fuses, and circuit breakers, ensuring secure operation in both classroom and laboratory environments.

Q: Where is this transformer trainer best suited for use?

A: It is ideal for engineering colleges, technical universities, and vocational training institutes. Its portability and bench-top mounting make it perfect for laboratory demonstrations, educational workshops, and hands-on training sessions.

Q: What accessories are included with the Power Transformer Trainer?

A: Each unit comes with patch cords for connections, a user manual for guidance, clearly labeled terminals for various voltage outputs, and indicator lamps for operational status. All components are conveniently housed within a portable metal case.

Q: What are the benefits of using color-coded binding posts and clearly labeled terminals?

A: Color-coded posts and labeled terminals simplify circuit connection, minimize errors, and enhance safety. They facilitate quick, intuitive setup, making experiments more effective, especially for students learning transformer basics.

Q: How do users perform voltage measurements and transformer tests on this trainer?

A: Users connect the input to the mains supply and select the desired output tap via accessible terminals. They can conduct short and open circuit tests, read voltage and current from analog meters, and observe protection mechanisms using the training panel.
