Portable Hydraulic Trainer

Get a Price/Quote

Portable Hydraulic Trainer Specification

Measurement Range
0-200 Bar (Pressure Gauge)

Frequency
50 Hz

Accuracy
100 %

Voltage
220 V AC

Feature
Highly Efficient

Temperature Range
-10C to 80C (Approx.)

Model No
PHT-2024

Power Source
Electric

Automation Grade
Semi-Automatic

Capacity
1 HP, 0.5 HP (Approx.)

Core Components
Hydraulic Pump, Directional Valve, Actuator, Pressure Gauges, Reservoir

Equipment Materials
Mild Steel Frame, Aluminum Panel, Standard Fluid Pipes

Type
Portable Hydraulic Trainer

Usage
Laboratory

Display Type
Analog Gauges

Dimension (L*W*H)
900 mm x 600 mm x 800 mm (Approx.)

Weight
Approx. 40-50 kg

About Portable Hydraulic Trainer

PORTABLE HYDRAULIC TRAINER

The portable hydraulic principle trainer is designed for common courses such as 'hydraulic control

technology', 'hydraulic and pneumatic transmission', which is widely used in industrial area and

school education. It is suitable for technical secondary school, junior college, vocational school,

mechanical engineering major education. By the experiment operation and course design, students

can understand the structure of hydraulic components, loop control principle, design method and so

on. The trainer is mainly composed of training box, oil tank, motor and gear pump (one body

design), hydraulic components, oil tubes and so on, with the advantage of small size, light weight,

easy to move. It is an excellent solution for the traditional teaching way that teachers can only

conduct the course in one place.

EXPERIMENTS OF PORTABLE HYDRAULIC TRAINER

Understanding of hydraulic components structure, signal and functions, Single stage pressure

regulating loop of overflow valve, One level pressure-relief loop of reducing valve, Oil in speed regulating loop of flow control valve, Oil return speed

regulating loop of flow control valve, Side oil line throttle governing loop of one way throttle valve, Reversing loop of hand directional valve, Series

speed regulating loop of flow control valve and throttle valve, Parallel speed regulating loop of flow control valve and throttle valve, Oil in and oil

return speed regulating and throttling loop

Disassembly and assembly of overflow valve, reducing valve, hand directional valve, Hydraulic cylinder, Throttle valve, Flow control valve, Self-locking

hydraulic connector

Comprehensive Hydraulic Training Solution

Engineered for education and skills development, the PHT-2024 Portable Hydraulic Trainer enables demonstrations and hands-on practice for over 12 hydraulic experiments. With core components such as hydraulic pump, directional valve, actuator, and precise analog gauges, this trainer supports both basic and advanced concepts, empowering users to gain a solid understanding of hydraulic systems.

Designed for Portability and Safety

The trainers leak-proof welded reservoir, durable lockable trolley, and quick release couplings make setup and movement easy and safe. At just 40-50 kg and with dimensions allowing for convenient handling, it fits a variety of laboratory spaces. Safety is prioritized with a pressure relief valve and emergency stop to ensure worry-free operation during experiments.

FAQs of Portable Hydraulic Trainer:

Q: How do you operate the Portable Hydraulic Trainer for laboratory experiments?

A: To operate the trainer, connect the desired hydraulic circuit using quick release couplings, ensure the reservoir is filled to capacity, and switch on the electric power source (220 V AC). Select your pump flow rate (0.82.5 LPM) and follow the experiment manual to set up the required experiment configuration safely.

Q: What types of hydraulic experiments can be conducted on this trainer?

A: This trainer supports more than 12 basic and advanced hydraulic experiments, including studies of pressure, flow, actuator movement, directional control, and load handling. It is ideal for learning system efficiency, safety devices, and the principles of hydraulics in a controlled setting.

Q: When is it recommended to use the emergency stop or pressure relief valve during operation?

A: The emergency stop should be used immediately if unsafe conditions are detected or if unexpected equipment behavior occurs. The built-in pressure relief valve automatically protects the system from overpressure during regular use, maintaining operator and equipment safety.

Q: Where can this Portable Hydraulic Trainer be best utilized?

A: The PHT-2024 is best suited for engineering colleges, technical institutes, and industrial training centers where hands-on learning and hydraulic circuit demonstrations are essential components of education and skill-building.

Q: What is the process for maintaining the hydraulic trainer for optimal performance?

A: Regularly check fluid levels, inspect hoses and fittings for wear, keep the analog gauges and aluminum panel clean, and perform visual checks on core components like the pump and valves. Ensure the power supply is stable and use only recommended hydraulic fluids for longevity.

Q: How does the portability and design benefit the user during training sessions?

A: With a robust lockable trolley and compact dimensions, the trainer can be easily moved between classrooms or labs. Quick release couplings make setup and changeover between experiments fast and efficient, minimizing downtime and maximizing instructional productivity.
