Plunger Pump Demonstration Unit

Get a Price/Quote

MOQ : 1 Piece

Plunger Pump Demonstration Unit Specification

Warranty
1 year

Accuracy
1% of full scale

Voltage
220V AC

Frequency
50 Hz

Product Type
Electric

Capacity
0.01 to 5 LPM (litres per minute)

Power Source
Electric

Model No
PPDU-24

Measurement Range
05 LPM (flow); 06 bar (pressure)

Feature
Capable of being linked to a not supplied via an interface console an essential accessory.

Automation Grade
Manual & Semi-automatic

Temperature Range
Ambient to 80C

Core Components
Plunger Pump, motor, pressure gauges, flow meters, water reservoir

Equipment Materials
Stainless Steel, Acrylic, Borosilicate Glass

Type
Plunger Pump Demonstration Unit

Usage
Educational laboratory, flow and pressure demonstration

Display Type
Analog and digital pressure indicators

Dimension (L*W*H)
Approx. 1000 x 600 x 900 mm

Weight
Approximately 40 kg

Application
Demonstration and study of positive displacement pump principles

Reservoir Capacity
15 liters

Safety Features
Overload protection, pressure relief valve

Noise Level
<70 dB

Mounting
Mobile trolley with castor wheels

Control Panel
Integrated with ON/OFF and speed control

Pump Head Material
Stainless Steel 304

Priming Method
Self-priming

Drive Motor Rating
0.5 HP

Suction/Discharge Tubing
Flexible PVC

Plunger Pump Demonstration Unit Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cheque, Telegraphic Transfer (T/T)

Sample Available
Yes

Main Export Market(s)
Asia, Central America, North America, South America, Africa, Australia, Eastern Europe, Western Europe, Middle East

Main Domestic Market
All India

Certifications
AS ISO 9001:2008, ISO 14001:2004 and OHSAS 18001:2007 CO.

About Plunger Pump Demonstration Unit

Plunger Pump Demonstration Unit

We are offering a wide range of fluid Mechanic lab equipment for engineering colleges. Our company offers optimum quality plunger pump demonstration unit at the most reasonable market price. This apparatus is manufactured under the supervision of expert professionals, using best quality raw materials. The apparatus manufactured by us is used for the purpose of measuring fluid flowing through an open channel. Offered apparatus is exclusively demanded in various hydraulic industries for accurate performance and hassle-free installation.

Specification of Plunger Pump Demonstration Unit :

Small scale plunger pump demonstration unit.
Capable of being linked to a not supplied via an interface console an essential accessory.
Supplied with software providing full instructions for setting up, operating, calibrating and performing the teaching exercises.
Facilities provided for logging, processing and displaying data graphically.

Comprehensive Learning Tool

The plunger pump demonstration unit is specifically developed for educational purposes, enabling the in-depth study of positive displacement pump operation, flow, and pressure characteristics. With an integrated control panel and dual display (analog and digital), students can observe real-time adjustments and results, fostering a practical learning environment.

Durable and Flexible Design

Constructed using high-quality stainless steel, acrylic, and borosilicate glass, the unit combines durability with safety. The mobile trolley and flexible PVC tubing ensure convenient movement and setup within the laboratory, while overload protection and a pressure relief valve safeguard both users and equipment during operation.

FAQs of Plunger Pump Demonstration Unit:

Q: How does the self-priming feature enhance usability in the plunger pump demonstration unit?

A: The self-priming mechanism allows the unit to start pumping without manual intervention to fill the pump housing, streamlining the setup process and enabling immediate operation during educational demonstrations.

Q: What are the main benefits of both analog and digital pressure indicators?

A: Having both analog and digital pressure indicators enhances measurement accuracy and provides students with clear, comparative readings, making it easier to interpret results and demonstrate pressure variation principles.

Q: When is it appropriate to use the overload protection and pressure relief features?

A: These safety features activate during abnormal conditions, such as unintended pressure spikes or excessive motor load, protecting both the unit and users from potential harm or equipment damage.

Q: Where can the plunger pump demonstration unit be utilized effectively?

A: The mobile trolley design allows the unit to be easily moved and used in diverse educational laboratory settings, including engineering labs, fluid mechanics courses, and training centers focused on pump technology.

Q: What is the typical process for conducting a demonstration with this unit?

A: Users begin by filling the reservoir, selecting speed and flow settings via the control panel, and observing flow and pressure outputs through the indicators. The self-priming feature ensures quick starts, while real-time data displays enable thorough analysis of operational behavior.

Q: How does this unit support educational objectives in laboratories?

A: The units manual and semi-automatic controls along with accurate measurement systems help illustrate pump mechanics, flow dynamics, and pressure profiles, supporting hands-on student engagement and experiential learning.
