Orifice Meter Apparatus

Price 500.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Orifice Meter Apparatus Specification

Model No
OME-102

Measurement Range
0.5 to 5 m/hr

Power Source
Electric (AC powered)

Voltage
220 V

Feature
Measurement of two phase flow is very important for geothermal steam field management.

Warranty
1 year

Temperature Range
Ambient to 80C

Frequency
50 Hz

Core Components
Orifice plate, measuring tank, manometer, pump, piping system

Accuracy
1% of full scale

Capacity
25 Liters (typical) Collection tank

Automation Grade
Manual

Equipment Materials
Stainless steel, acrylic, brass fittings

Type
Training equipment

Usage
Measurement and calibration of flow rate using orifice meter

Display Type
Bourdon type pressure gauge

Dimension (L*W*H)
1200 mm x 400 mm x 1200 mm

Weight
Approx. 35 kg

Orifice Meter Apparatus Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Orifice Meter Apparatus

Sharp Edge Orifice Meter

We are manufacturers of finest Sharp Edge Orifice Meter in India and also supplies and exporters Sharp Edge Orifice Meter around the world at best prices. To enquire Sharp Edge Orifice Meter, please fill below form. Well be back with you.

Measurement of two phase flow is very important for geothermal steam field management.
Existing measurements techniques are reviewed and the advantages of the sharp edge orifice plate are presented.
Existing two phase flow correlations using the orifice plate are examined using field data from several geothermal fields.
It was demonstrated that none of the existing correlations can be universally applied without case by case calibration.
A new time discreet model was developed and tested and is currently used by the geothermal industry.

Accurate Flow Measurement for Diverse Applications

Engineered for both reliability and precision, the Orifice Meter Apparatus provides hands-on training in the measurement and calibration of fluid flow rates. Its centrifugal pump and transparent U-tube manometer enable clear demonstrations of core hydraulic principles, essential for geothermal steam field management and related studies. The standard 12 mm orifice plate can be customized to fit various experimental requirements.

Safe and User-Friendly Design

With overload and overheat protection, this apparatus safeguards both the user and equipment during operation. The ergonomic hand-operated valve gives intuitive flow control, while the visible measuring tank (25 L) and Bourdon type pressure gauge enhance ease of use. The bench or floor mount flexibility ensures convenient setup in any laboratory environment.

FAQs of Orifice Meter Apparatus:

Q: How is the flow rate measured using the Orifice Meter Apparatus?

A: The flow rate is determined by observing the differential pressure across the orifice plate, read from the U-tube manometer. Manual data recording and easy adjustments via the hand-operated valve aid in precise measurement and calibration.

Q: What are the main components included in the OME-102 system?

A: This model includes a stainless steel orifice plate, centrifugal pump, acrylic U-tube manometer, measuring tank (25 L), brass and acrylic fittings, and a Bourdon pressure gauge. Piping, manual flow control, and overload protection are also integrated.

Q: When should the overload and overheat protection be checked?

A: It is advised to verify the proper function of overload and overheat protection before each use, particularly in high-demand or continuous operation scenarios, to prevent any equipment damage or hazards.

Q: Where can the Orifice Meter Apparatus be installed?

A: The apparatus is versatile and can be mounted on a benchtop or placed on the floor, depending on laboratory space and experimental needs.

Q: What is the benefit of using a transparent acrylic manometer in this setup?

A: The transparent acrylic U-tube manometer allows clear visualization of fluid levels, making differential pressure readings more accurate and easily observable during demonstrations or experiments.

Q: How is data recorded and what is the accuracy of this equipment?

A: Data is recorded manually using readings from the manometer and pressure gauge. The apparatus offers a measurement accuracy of 1% of full scale, ensuring reliable experimental results.
