Orifice and Mouthpiece Apparatus

Get a Price/Quote

MOQ : 1 Piece

Orifice and Mouthpiece Apparatus Specification

Accuracy
1% (measurement dependent)

Measurement Range
5 LPM to 25 LPM (liters per minute)

Warranty
1 year

Temperature Range
5C to 45C

Model No
OME/2024

Feature
Easy to operate, robust structure, corrosion resistance, portable

Voltage
220V AC

Product Type
Electric

Core Components
Water tank, Orifice, Mouthpiece, Measuring Tank, Piezo-meter Tube Board, Sump, Pump

Capacity
10-15 Liters (typical water tank)

Frequency
50 Hz

Automation Grade
Manual

Power Source
Electric

Equipment Materials
Powder-coated mild steel frame, borosilicate glass, brass and stainless steel fittings

Type
Orifice and Mouthpiece Apparatus

Usage
Laboratory

Display Type
Analog scale and piezometer tubes

Dimension (L*W*H)
900 mm x 450 mm x 1000 mm (approx.)

Weight
Approx. 35-45 kg (varies with model)

Safety
Overload protector for pump, non-slip feet

Pump Type
Centrifugal, 0.5 HP electric motor

Orifice and Mouthpiece Diameter
10 mm and 15 mm (removable types)

Number of Piezo Tubes
8 to 12 tubes for pressure head measurement

Test Fluids
Water (standard), compatible with other low-viscosity liquids

Discharge Measurement Tank
Graduated, 25 L capacity with a calibrated stop watch for time measurement

Recommended Use
Civil, mechanical, and hydraulic laboratory experiments

Orifice and Mouthpiece Apparatus Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Africa, Asia, Eastern Europe, Western Europe, Middle East

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Orifice and Mouthpiece Apparatus

Orifice and Mouthpiece Apparatus

Our company offers optimum quality Orifice and Mouthpiece Apparatus at the most reasonable market price. This apparatus is manufactured under the supervision of expert professionals, using best quality raw materials. The apparatus manufactured by us is used for the purpose of measuring fluid flowing through an open channel. Offered apparatus is exclusively demanded in various hydraulic industries for accurate performance and hassle-free installation.

Experiments:

To determine the co-efficient of discharge of different Orifice and mouthpiece.

Utilities Required:

Electric supply 0.5 kW, 220V AC, Single Phase.
Water supply Tap water connection.
BSP Distilled water @ 60 liters (optional).
Floor Area with Drain facility.

Technical Specifications:

Sudden Enlargement: From 13 mm to 23 mm.
Sudden Contraction: From 20 mm to 16 mm.
Electric supply: 0.5 kW, 220V AC, Single Phase.

Core Features for Accurate Experimentation

The apparatus is engineered with eight to twelve piezo tubes enabling thorough measurement of pressure head, and precision discharge measurement via a graduated tank. Its modular orifice and mouthpiece configuration allow different test setups. Safety is prioritized with overload protection and non-slip feet, while borosilicate glass, stainless steel, and powder-coated frame ensure durability and corrosion resistance.

Designed for Educational and Research Environments

Perfect for civil, mechanical, and hydraulic laboratory experiments, this manual, electric-powered apparatus delivers dependable results and intuitive usability. For instructors and students alike, it supports a range of flow rates and measurement scenarios, enhancing experimental learning and hydraulic studies with its analog displays and reliable pump operation.

Easy Operation and Maintenance

The Orifice and Mouthpiece Apparatus is built to be user-friendly, featuring removable orifice/mouthpiece components for quick changeovers, a sump for ease of water handling, and a portable structure. Maintenance tasks are minimized by quality materials and straightforward assembly, while all measurements are visually accessible for clear data collection.

FAQs of Orifice and Mouthpiece Apparatus:

Q: How is the flow rate measured using the Orifice and Mouthpiece Apparatus?

A: The flow rate is determined by collecting discharged fluid in the 25-liter graduated measurement tank and recording the elapsed time with the calibrated stopwatch. Data from the piezometer tubes can further correlate pressure head and discharge for precise experiment results.

Q: What types of fluids can be used with this apparatus during experiments?

A: Although water is standard, the apparatus is compatible with other low-viscosity liquids, allowing for flexibility in laboratory testing and research across varied hydraulic conditions.

Q: When should the removable orifice and mouthpiece be changed?

A: Change the 10 mm or 15 mm removable orifice or mouthpiece when the experiment protocol specifies different diameters, permitting comparative studies of fluid flow or calibration of results for various sizes.

Q: Where is this apparatus best suited for use?

A: It is recommended for civil, mechanical, and hydraulic laboratories in academic institutions, research centers, and industrial settings, thanks to its robust design, portability, and accuracy.

Q: What is the process for operating the apparatus?

A: Fill the water tank, select and install the appropriate orifice or mouthpiece, power on the centrifugal pump, and record pressure head using the piezometer tubes. Measure discharge volume in the tank while tracking time with the stopwatch, and document readings on the analog scale.

Q: How does the overload protector enhance operational safety?

A: The built-in overload protector automatically shuts down the pump if electrical or mechanical overload is detected, ensuring both user safety and longevity of the equipment.

Q: What are the main benefits of using this apparatus for hydraulic laboratory experiments?

A: Key advantages include ease of operation, robust construction, high measurement accuracy (1%), corrosion resistance, and adaptability to various experimental test fluids and setup configurations.
