Orbital Shaking Incubator

Price 1000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Orbital Shaking Incubator Specification

Operate Method
Digital control panel with RPM and temperature setting

Voltage
220V

Classification
Specially designed to have a combined operation of Incubation and shaking as well as integral shaker mechanism, eccentric orbital drive provides horizontal orbital motion agitation. Incubator is double walled. Exterior of mild steel finished in powder coated. Interior made of stainless steel. Chamber illumination with fluorescent light.

Dimension (L*W*H)
Approx. 660 x 510 x 850 mm

Application
Research laboratories, microbiology, biotechnology, cell culture

Material
Mild Steel

Power
220V AC 50Hz single phase. Volt (v)

Usage
Laboratory incubation and shaking of samples

Product Type
Orbital Shaking Incubator

Weight
Approx. 60-70 kg

Color
White with blue accent (as per image)

Capacity
Approx. 16-20 flasks (250 ml each)

Orbital Shaking Incubator Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Middle East, Africa, Eastern Europe, Western Europe

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Orbital Shaking Incubator

Orbital Shaking Incubator ETS-56E

Specially designed to have a combined operation of Incubation and shaking as well as integral shaker mechanism, eccentric orbital drive provides horizontal orbital motion agitation. Incubator is double walled. Exterior of mild steel finished in powder coated. Interior made of stainless steel. Chamber illumination with fluorescent light.

Glass-wool insulation between the two walls. Temperature is controlled by Digital Display Temperature Controller cum Indicator. Forced air circulation is provided. The platform is mounted on heavy duty springs with lotus clamps and S.S. top. Speed is continuously variable from 50 to 250 RPM and displayed on a Digital Speed Meter (optional). It works on 220V AC 50Hz single phase.

Temperature Range : Ambient 5C to 600C

Capacity	Flasks
250 ml	9
250 ml	16
250 ml	25
250 ml	36
500 ml	9
500 ml	16
500 ml	25
500 ml	36

Optional :

Digital Speed Meter
Digital Timer of 999 minutes
Digital temp. indicator-cum-controller.
Digital temp. indicator-cum-controller with computer data logger.

Temperature range is 5C to 60C.

Advanced Temperature and Shaking Control

This incubator features a PID microprocessor for precise thermal regulation and an orbital shaker mechanism for uniform agitation. The digital LED display allows users to set and monitor both temperature and speed effortlessly, supporting experimental reproducibility and reliability.

Durable and User-Friendly Design

With a sturdy double-walled constructionpowder-coated mild steel exterior and stainless steel interiorthis incubator is built for longevity and ease of cleaning. The front-opening, glass-paneled door provides clear visibility, while internal illumination aids in sample inspection.

Versatile Applications

Ideal for laboratories in the fields of microbiology, biotechnology, and cell culture, this incubator accommodates up to 16-20 standard 250 ml flasks. The programmable timer and adjustable shaking orbit (20 mm) further enhance usability for a variety of research protocols.

FAQs of Orbital Shaking Incubator:

Q: How does the orbital shaking incubator maintain temperature accuracy during experiments?

A: The incubator uses a PID microprocessor-based temperature control system, which continuously monitors and adjusts the internal conditions to maintain the set temperature within 0.5C, ensuring consistent experimental conditions.

Q: What types of laboratory applications is this incubator suitable for?

A: This incubator is designed for laboratory incubation and shaking of samples, making it ideal for microbiology, biotechnology research, and cell culture processes requiring controlled temperature and continuous agitation.

Q: When should the timer function be used during incubation?

A: The programmable timer, which ranges from 0 to 999 minutes, is best utilized to automate processes that require specific incubation periods, such as timed shaking or incubation cycles, allowing for precise experimental timing without manual intervention.

Q: Where can this orbital shaking incubator be installed?

A: Due to its compact footprint (approx. 660 x 510 x 850 mm) and standard 220V AC power requirement, the incubator is suitable for installation in most research laboratories, such as those in universities, medical institutions, and biotech companies.

Q: What is the process for setting shaking speed and temperature?

A: Settings are adjusted through a digital control panel. Users can easily set the desired RPM (20300) and temperature (5C above ambient to 60C) using the digital LED interface, ensuring both ease of use and operational precision.

Q: What are the main benefits of using this combined incubator and shaker?

A: The main benefits are precise environmental control for samples, efficient mixing due to orbital shaking, user-friendly operation, programmable timing, and robust construction, all contributing to reliable and reproducible laboratory results.
