Mortuary Chamber

Get a Price/Quote

MOQ : 1 Piece

Mortuary Chamber Specification

Material
Stainless Steel, PU insulation

Capacity
Four Bodies

Dimension (L*W*H)
2340 mm x 850 mm x 1620 mm

Voltage
220V, 50Hz

Application
Medical Anatomy Instrument

Power
900W

Weight
Approx 420 kg

Classification
Medical Equipment

Color
White / Silver

Product Type
Mortuary Chamber

Operate Method
Digital Control Panel

Usage
Medical Anatomy Instrument

Humidity Control
Yes

Sound Level
Low-noise operation

Door Type
Individual locking doors

Cooling System
Hermetically sealed compressor

Defrost System
Automatic

Refrigerant
R134A Eco-Friendly

Accessories
Castor wheels for mobility

Safety Features
Overheat protection, Door lock

Display
LED Digital Temperature Display

Internal Tray
Removable stainless steel trays

Temperature Range
2C to 8C

Mortuary Chamber Trade Information

Minimum Order Quantity
1 Piece

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Mortuary Chamber

Mortuary Chamber

Mortuary Chamber is specially designed to accommodate cadaverous under cool condition to prevent decomposition and offering vast space saving advantage over the conventional types together with greater hygiene.

Double- walled with steel panel for outer surface and stainless steel inner chamber with insulation in between, front opening hinged insulated doors lined with magnetic gasket, handle and lock arrangement with keys in duplicate for individual dead travel on rollers fitted with ball bearing for easy movement. Exterior surface of Mortuary Storage Cabinets is chemically treated against coated and duly finished with hammer tone paint. To avoid any moving part in side the cabinet for easier maintenance and cleaning view point, refrigeration unit is kept outside the chamber and fixed at near top. Temperature of -20C to 50C or - 15 to 200C is maintained by hermetically sealed refrigerator unit. Temperature controller is mounted on front panel, provided on front top, along with pilot lamp, main switch etc. supplied complete with trays, cord and plug. Suitable to work on 220 volts AC.

Technical Specification Of Mortuary Chamber

Capacity Temp. Voltage Stabilizer

Single Body 2 C - 6C 3 KVA

Two Bodies 2 to 6 C 4 KVA

Three Bodies 2 to 6 C 5 KVA

Four Bodies 2 to 6 C 8 KVA

Six Bodies 2 to 6 C 8 KVA

Industries where this product is used

Institutes, Medical Colleges, Industries, Pharmacy colleges and Industry, Laboratories, Pharmaceutical Industry, Hospitals, etc.

Superior Cooling and Security

Engineered with a hermetically sealed compressor and individual locking doors, the Mortuary Chamber maintains a precise temperature range of 2C to 8C. Its eco-friendly refrigerant, advanced insulation, and overheat protection system ensure optimal storage and unmatched product safety for anatomical applications.

User-Centric Design and Operation

The chamber includes removable stainless steel trays for easy cleaning and handling. The LED digital temperature display and digital control panel provide intuitive operation, while automatic defrost and humidity control technologies simplify maintenance and promote preservation integrity.

Mobility and Robust Construction

With built-in castor wheels, the Mortuary Chamber offers easy mobility even in tight laboratory spaces. Crafted from stainless steel with PU insulation, it is robust and hygienic, supporting a load of up to four bodies. Its white or silver finish suits diverse medical environments.

FAQs of Mortuary Chamber:

Q: How does the Mortuary Chamber maintain consistent temperatures for preservation?

A: The Mortuary Chamber uses a hermetically sealed compressor and eco-friendly R134A refrigerant, maintaining an internal temperature range of 2C to 8C. The digital control panel and LED display allow precise monitoring and adjustments to ensure optimal storage conditions.

Q: What safety features are included in this mortuary chamber?

A: The chamber has multiple safety features, including individual locking doors for added security, an overheat protection system, and long-lasting stainless steel construction. These ensure both the safety of stored specimens and compliance with medical regulations.

Q: When should the internal trays be removed and cleaned?

A: The removable stainless steel trays should be cleaned and sanitized after every use or whenever changing stored specimens, following standard hospital or laboratory protocols to prevent cross-contamination and maintain hygiene.

Q: Where can the Mortuary Chamber be installed for optimal operation?

A: The mortuary chamber is designed for flexibility, with castor wheels allowing mobility. Place it in a well-ventilated, temperature-controlled room with access to a 220V, 50Hz power supply. Ensure space around the unit for proper airflow and service access.

Q: What is the process for adjusting temperature or other settings?

A: Settings such as temperature and humidity can be adjusted using the digital control panel. The user-friendly interface and the LED digital display make it easy to program and monitor the desired conditions, ensuring reliable operation.

Q: Who benefits from using this Mortuary Chamber?

A: Medical institutions, anatomy labs, hospitals, and research centers benefit from this chambers reliable preservation, hygienic design, and ease of operation. Its four-body capacity, durability, and safety features make it ideal for professional anatomical storage.
