Send InquiryInverted Tissue Culture Microscope
Price 1000.0 INR/ Piece
MOQ : 1 Piece
Inverted Tissue Culture Microscope Specification
- Focus System
- Coarse and fine coaxial focusing mechanism
- View Head
- Trinocular; inclined 45, rotatable
- Spare Parts
- Supplied with dust cover, fuse, spare lamp, and additional immersion oil (on request)
- Features
- Anti-fungal optics, ergonomic design, suitable for prolonged observation of living cells and tissue cultures.
- Theory
- Inverted microscope designed for tissue culture applications, providing clear imaging of cells and tissues in petri dishes and flasks.
- Drawtube
- Trinocular head (for camera and binocular viewing)
- Sensor
- Compatible with digital camera adapters (camera not included)
- Resolution
- Optical resolution depends on objectives used; typically up to 1000x magnification with achromatic lenses.
- Interface
- Standard trinocular port for camera attachment
- Frame Rate
- Dependent on attached camera; not applicable to optical system only
- Focal Distance
- Working distance depends on objectives; standard is 7mm (for 10x objective) and 1.5mm (for 40x objective).
- Magnification
- 40x to 400x (standard with supplied objectives), extendable up to 1000x with optional objectives.
- Dimensions
- Approx. 400mm x 240mm x 450mm (L x W x H)
- Focus Range
- Fine and coarse focusing with long travel to accommodate varied vessel thicknesses.
- Eyepieces
- WF10X (Wide Field 10x), paired eyepieces
- Eyepiece Tube
- Inclined at 45, rotatable 360
- Illumination
- Built-in halogen or LED illumination with variable intensity control
- Coarse Adjustment Range
- 20mm
- Fine Adjustment Range
- 0.002mm precision
- Working Stage
- Mechanical stage with low-position coaxial controls; moveable stage for holding petri dishes and flasks
- Still Image Capture Resolution
- Dependent on attached camera
- Video Capture Resolution
- Dependent on attached camera
- Image Format
- Compatible with standard digital camera (for still image and video capture via camera)
- Interpupillary Distance
- Adjustable, 5575 mm
- Objective Achromatic
- Achromatic objectives; 4x, 10x, 40x (phase contrast optional)
- Condenser
- Condenser NA 0.3, Long Working Distance (LWD)
- Light Source
- 6V/20W halogen lamp or LED module, with adjustable brightness
- Input Voltage
- 220V AC / 50Hz (standard); 110V optional.
- Color
- White/grey professional laboratory finish.
- Stage Plate
- Fitted with transparent glass and optional metal insert for larger culture vessels.
- Body Material
- Pressure die-cast aluminum body for stability and durability.
- Camera Port
- Dedicated camera port for image and video capture.
- Nosepiece
- Quadruple revolving nosepiece with positive click stops.
- Stage Size
- 180mm x 155mm approx.
- Safety Standard
- CE certified (model dependent).
- Stage Controls
- Ergonomically placed coaxial controls for XY movement.
- Application
- Tissue culture, IVF, cell biology, live cell imaging, research and laboratory use.
- Phase Contrast Attachment
- Provided with focusable phase contrast condenser (slider or turret type as per model), suitable phase objectives.
Inverted Tissue Culture Microscope Trade Information
- Minimum Order Quantity
- 1 Piece
- Payment Terms
- Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)
- Sample Available
- Yes
- Sample Policy
- Sample costs shipping and taxes has to be paid by the buyer
- Packaging Details
- carton box, export quality also available
- Main Export Market(s)
- Asia, Eastern Europe, Western Europe, Middle East, Africa
- Main Domestic Market
- All India
- Certifications
- ISO 9001, 14001 ,CE
About Inverted Tissue Culture Microscope
Inverted Tissue Culture Microscope ETMS-139Inverted Tissue Culture Microscope is designed to observe tissue cultures, protozoans, planktons and any type of microbes in liquid media in cavity slides, cavity blocks, watch glasses or petri dishes etc. Involving wide range of applications.
Mounted on a pole and can be positioned in vertical height range upto 140 mm. Complete with koehler's illumination system with focused condenser lens with iris-diaphragm filter-carrier etc.
ETMS-139 :
Binocular observation head inclined at 45 with wide field10X eyepiece (Pair) & PH 5X, PH 10X, PH 20X, PH 40XAchromatic objectives
ETMS-139(i)
With Trinocular observation head with 10X wide field eyepiece (Pair) & PH 5X, PH 10X, PH 20X, PH 40Xobjectives
Unmatched Clarity and Versatility for Tissue Culture
This microscope enables precise visualization of live cells and cultures, thanks to its phase contrast condenser and high-quality achromatic objectives. The mechanical stage and ergonomic controls accommodate diverse vessel sizes, making it a versatile tool for research and clinical applications in cell biology, IVF, and more.
Advanced Imaging Capabilities for Research
Equipped with a dedicated camera port and standard trinocular head, this microscope supports seamless attachment of digital cameras for capturing both still images and videos. It is suitable for documentation, analysis, and remote collaboration, enhancing the capabilities of modern research labs.
FAQs of Inverted Tissue Culture Microscope:
Q: How is the phase contrast feature of this inverted microscope beneficial for tissue culture observation?
A: The phase contrast condenser, either slider or turret type, enhances visualization of transparent or unstained live cells in tissue cultures, making internal structures more visible without the need for staining, which could harm cells.Q: What applications can this microscope be used for in a laboratory or research setting?
A: Common applications include tissue culture monitoring, IVF, cell biology research, live cell imaging, and other laboratory studies that require close observation of living cells and tissues in culture flasks or petri dishes.Q: How does the camera port function, and what types of cameras can be attached?
A: The dedicated camera port is standard trinocular, compatible with most digital camera adapters (camera not included). This allows for clear still image capture and video recording for documentation or analysis, depending on the camera used.Q: When should I use the metal insert for the stage plate?
A: The optional metal insert for the stage plate is recommended when working with larger or heavier culture vessels, providing extra stability and support during observation.Q: What are the benefits of the microscopes pressure die-cast aluminum body?
A: A pressure die-cast aluminum frame ensures enhanced durability and stability, minimizing vibrations and ensuring accurate, clear imaging during sensitive cell culture work.Q: How do I control the magnification and focus when observing samples?
A: The microscope features quadruple revolving nosepiece with achromatic objectives (4x, 10x, 40x), wide field 10x eyepieces, and fine and coarse coaxial focusing mechanisms for precise control over magnification and focusing, adaptable to various vessel thicknesses.Q: Where is this microscope typically manufactured and exported from?
A: This model is manufactured, supplied, and exported from India, meeting international standards including CE certification depending on the model.
