Hydraulics Bench

Name: Hydraulics Bench
Brand: EDUTEK INSTRUMENTATION

Get a Price/Quote

MOQ : 1 Piece

Hydraulics Bench Specification

Measurement Range
0.5 LPM to 25 LPM

Voltage
220V AC

Warranty
1 year

Frequency
50 Hz

Accuracy
±1%

Automation Grade
Manual

Temperature Range
10°C to 40°C

Model No
HYDBENCH-01

Core Components
Pump, Flow Control Valve, Measuring Tank, Stop Watch, Sump Tank

Power Source
Electric

Feature
Mobile on castor wheels, corrosion resistance, easy drainage and maintenance

Capacity
40 Liters

Equipment Materials
Powder coated mild steel frame, Stainless steel working surface and tanks

Type
Laboratory Hydraulics Bench

Usage
Educational, Fluid Mechanics Laboratory Experiments

Display Type
Analog

Dimension (L*W*H)
1200 x 600 x 900 mm

Weight
Approx. 50 kg

Connections
Standard hose barbs for flexible/open-ended setups

Water Supply
Self-contained with closed water circuit

Pump Type
Monoblock centrifugal with on/off switch

Noise Level
Less than 65 dB

Drainage Facility
Quick drain valve for easy water change

Mobility Feature
Heavy-duty casters for easy movement

Flow Measurement
Volumetric via graduated tank, stopwatch supplied

Overload Protection
Built-in thermal overload protector for motor

Pump Capacity
0.5 HP centrifugal

Sump Tank Capacity
40 Liters gross, 30 Liters working

Tank Material
SS 304 Stainless Steel

Plumbing Fittings
Brass and PVC connectors

Working Table Material
Polycarbonate sheet

Hydraulics Bench Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Delivery Time
2 Week

Sample Available
No

Main Export Market(s)
Australia, Central America, North America, South America, Middle East, Africa, Asia, Eastern Europe, Western Europe

Main Domestic Market
All India

Certifications
O 9001:2008, ISO 14001:2004 and OHSAS 18001:2007 CO.

About Hydraulics Bench

HYDRAULICS BENCH

Edutek Instrumentation are Manufacturer and Supplier Company in India,We are Exporter in India and other country ,Hydraulic Bench for engineering college and engineering Training Equipment. Hydraulic Bench Asseries Exporter for Engineering .

A dump valve in the base of the volumetric tank is operated by a remote actuator. Opening the dump valve returns the measured volume of water to the sump in the base of the bench for recycling. An overflow in the volumetric tank avoids flooding.

Water is drawn from the sump tank by a centrifugal pump and a panel mounted control valve regulates the flow.

Precise and Reliable Flow Measurement

The hydraulics bench employs a volumetric flow measurement technique using a graduated tank and stopwatch for accurate data collection. With an accuracy of 1%, it ensures dependable results during laboratory experiments, making it well-suited for educational institutions and research facilities focused on fluid mechanics.

Durable & Corrosion-Resistant Construction

Featuring a powder-coated mild steel frame, SS 304 stainless steel tanks, and polycarbonate working surfaces, the bench is engineered for longevity and inferior maintenance requirements. Brass and PVC plumbing further enhance corrosion resistance, ensuring smooth operation over years of constant use.

Easy Mobility and Efficient Drainage

Heavy-duty casters allow the unit to be easily moved throughout the laboratory space. The quick drain valve simplifies water replacement, supporting efficient workflow and rapid experimental setup. These features make the HYDBENCH-01 practical for dynamic educational environments.

FAQs of Hydraulics Bench:

Q: How does the HYDBENCH-01 measure water flow during experiments?

A: The bench measures water flow volumetrically using a graduated stainless steel tank and a supplied stopwatch. By timing the collection of water to a specific volume mark, accurate flow rates are calculated for a range between 0.5 LPM and 25 LPM.

Q: What advantages does the self-contained closed water circuit provide?

A: The closed water circuit minimizes water wastage by recirculating water, enabling experiments without the need for an external water supply. This design ensures reliable, repeatable results, while conserving resources and simplifying both setup and cleanup.

Q: When should the quick drain valve be used?

A: Use the quick drain valve to efficiently drain and change water between experiments or at the end of laboratory sessions. This helps maintain water quality and hygiene, and streamlines equipment maintenance.

Q: Where is the HYDBENCH-01 best utilized?

A: This hydraulics bench is ideal for educational and research settings, particularly for fluid mechanics laboratory experiments in universities, technical institutes, and engineering colleges.

Q: What is the benefit of the benchs mobility feature?

A: With heavy-duty casters, the bench can be easily relocated within the lab for convenient storage or collaborative experiments, adapting to the flexible needs of modern educational environments.

Q: How does the built-in thermal overload protector enhance safety?

A: The thermal overload protector safeguards the pump by automatically shutting it off in the event of overheating, preventing damage and ensuring safe, reliable operation during extended experimental sessions.
