Heating Mantle

Get a Price/Quote

MOQ : 1 Piece

Heating Mantle Specification

Power Supply
230V±10%, 50 Hz

Shape
Hemisphere (to suit round bottom flask)

Heating Capacity
Adjustable depending on model and sample size

Accuracy
±5°C (with temperature controller accessory)

Glass Type
No glass contact; designed for use with round bottom flasks

Features
Uniform heating, spill-proof design, energy efficient, replaceable heating element

Temperature Resistance
Up to 450°C

Display Type
Analog (Digital optional)

Control Type
Manual (with optional Thermostat/Temperature controller)

Type
Laboratory Heating Mantle

Dimension (L*W*H)
150 mm x 150 mm x 180 mm (for 1 Ltr capacity)

Equipment Type
Laboratory Heating and Stirring Apparatus

Equipment Materials
Outer body made of mild steel powder coated; heating element wound on glass fibre

Power
250-1000W (varies by model)

Voltage
220-240V AC

Material
Mild Steel, Glass Fibre, Nichrome Wire

Application
Heating solutions in laboratories, chemical labs, and educational institutions

Capacity (Ltr)
1 Ltr (available models: 50 ml to 20 Ltr)

Operating Temperature
Ambient to 450C (max)

Insulation
High-grade glass wool insulation to prevent heat loss

Cable Length
1.5 meters (approx.)

Color
Blue/White (Standard)

Max Flask Capacity
Suitable up to 20 Ltr round bottom flask (depending on model)

Safety
Earth grounded for shock protection

Element Protection
Features replaceable element with protection grille

Weight
Approximately 2.5 kg (for 1 Ltr model)

Temperature Control
Step-regulator/energy regulator standard; digital controller optional

Heating Mantle Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Heating Mantle

HEATING MANTLE

Hand knitted heating nets of glass yarn which are joint-less to withstand high temperature.Single individual size. Body is made of one piece spun aluminum and is lagged with special mineral wool. Panel is provided with on-off switch, energy control knob, pilot lamp etc. Supplied complete with cord-plug.

With built in heating zone switch in acid proof,
Plastic housing
Flexible heating element for use
Round bottomed flasks
Temperature up to 450 degree centigrade
Two heating zones
Power 230v,50/60Hz

Advanced Thermal Insulation

Equipped with high-grade glass wool insulation, the heating mantle efficiently retains heat and minimizes energy loss. This feature is especially valuable in laboratories that demand consistent temperatures, ensuring optimal heating performance and improved energy efficiency.

Versatile Flask Capacity

Available in models ranging from 50 ml to an impressive 20 liters, the heating mantle caters to a wide variety of laboratory applications. Its hemispherical shape is tailored to fit round-bottom flasks, making it ideal for both routine and large-scale experiments.

Precision Temperature Control

The heating mantle offers flexible control with options for manual regulation or optional digital controllers. This allows users to adjust heating from ambient up to 450C as required, ensuring experimental accuracy and repeatability across diverse procedures.

Built-In Safety Features

Safety is enhanced through an earth-grounded design for shock protection and a protective grille over the replaceable heating element. These features contribute to secure operation, reducing the risk of accidents and ensuring peace of mind for users.

FAQs of Heating Mantle:

Q: How do I operate the Heating Mantle with Insulation for laboratory applications?

A: Begin by selecting the suitable mantle size for your flask (from 50 ml to 20 Ltr). Connect the device to a standard 220240V AC power supply, place your round-bottom flask into the mantle, and use the step-regulator or optional digital controller to set your desired temperature (up to 450C). Always ensure safety by grounding the equipment properly before use.

Q: What is the benefit of glass wool insulation in this heating mantle model?

A: The high-grade glass wool insulation significantly reduces heat loss, resulting in efficient energy utilization. This both decreases operating costs and maintains stable, uniform heating, which is essential for accurate lab results.

Q: When should I replace the heating element, and how is this process done?

A: The heating element should be replaced when you notice inconsistent heating or reduced performance. To replace, first disconnect the power supply, remove the protection grille, and swap the old element with a compatible new one. Follow manufacturer guidelines for safety and optimal results.

Q: Where is this Heating Mantle most effectively used?

A: It is ideally used in chemistry laboratories, educational institutions, and research facilities where precise and safe heating of round-bottom flasks is required. Its spill-proof and robust design makes it perfect for routine sample preparations and chemical reactions.

Q: What type of temperature control does the Heating Mantle offer?

A: Standard models feature a manual step-regulator for adjustable heating. Digital controllers are available as optional accessories, offering 5C accuracyideal for experiments demanding precise temperature regulation.

Q: How does the mantle ensure safety during operation?

A: Safety is provided by an earth-grounded construction for shock protection and a protective grille enclosing the heating element. These measures prevent accidental shocks and element damage, prioritizing user safety in every usage scenario.

Q: What are the advantages of having a replaceable heating element and protection grille?

A: This design allows easy maintenance and enhances the products lifespan. Users can replace just the heating element as needed, reducing downtime and recurring costs. The protection grille shields the element from accidental spills and impacts, contributing further to safety and durability.
