FLUIDIZED BED DRYER APPARATUS

Price 13500.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

FLUIDIZED BED DRYER APPARATUS Specification

Application
Mass Transfer Lab Equipments

Warranty
1 Year

Material
Borosilicate Glass

Product Type
FLUIDIZED BED DRYER APPARATUS

Usage
Mass Transfer Lab Equipments

Feature
The set-up fitted with a speciallydesigned, vertical Glass Column. The lower portion of the column is filled withfluidizing material. The material is supported on the screen mesh held betweentwo flanges. Air from a compressor is heated in the heater box and passedthrough the column. Flow control and by-pass valve are fitted to regulate theairflow. At the top outlet of column a cyclone is provided to collect any solidparticles taken out by the air stream.

Type
1 Phase, 220 V AC, 3 kW.

FLUIDIZED BED DRYER APPARATUS Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Letter of Credit (L/C), Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T)

Packaging Details
Carton Box, Export Quality also Available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001, CE

About FLUIDIZED BED DRYER APPARATUS

Specification:

FLUIDIZED BED DRYER APPARATUS

Description:

This is a dryer in which moistureremoval takes place by fluidization of solids particles by hot air.

The set-up fitted with a speciallydesigned, vertical Glass Column. The lower portion of the column is filled withfluidizing material. The material is supported on the screen mesh held betweentwo flanges. Air from a compressor is heated in the heater box and passedthrough the column. Flow control and by-pass valve are fitted to regulate theairflow. At the top outlet of column a cyclone is provided to collect any solidparticles taken out by the air stream.

Experimentation:

To study the fluidized bed drying.

To plot the drying curve underfluidized bed condition.

Utilities Required:

Electricity Supply: 1 Phase, 220 V AC, 3 kW.

Granular and free flowing solid ofsize 1 to 2 mm.

Technical Details:

Control panel comprises of :

Digital Temp. Controller: 0 199.9C (For Hot Air) Standardmake on/off switch, Mains Indicator etc.

Column: Material Borosilicate Glass Dia. 80 mm. Total Length 500mm.

Cyclone Separator: Material Stainless Steel, CompatibleCapacity with collector.

Air Circulation: By forced draft fan, Arrangement is done varythe air flow rate.

Heating Chamber: Compatible capacity

Heater: Nichrome wire heater

Temperature Sensors: RTD PT-100 type.

Optimized Mass Transfer Solution

This fluidized bed dryer apparatus is specifically crafted for thorough demonstration and experimentation of mass transfer concepts in laboratories. Its transparent borosilicate glass column allows clear observation of the drying and fluidization process, making it an indispensable teaching and research tool.

Sturdy and User-Friendly Design

Accuracy and safety are ensured with a heat-resistant column, heated air flow regulated by calibrated valves, and an efficient cyclone separator. Assembly and operation are straightforward, enabling seamless integration into existing lab setups. Its single-phase, 3 kW system provides reliable performance with easy maintenance.

FAQ's of FLUIDIZED BED DRYER APPARATUS:

Q: How does the fluidized bed dryer apparatus work in a mass transfer laboratory setting?

A: The fluidized bed dryer operates by passing heated air through a column containing the material to be dried, causing the material to fluidize and enabling rapid moisture removal. Adjustable controls allow for precise airflow and temperature regulation, making it well-suited for mass transfer studies.

Q: What materials are used to construct this apparatus, and why is borosilicate glass preferred?

A: This apparatus is mainly constructed from borosilicate glass, known for its high thermal resistance and non-reactive properties, which ensure safe operation at elevated temperatures and clear visualization during experiments.

Q: When should this fluidized bed dryer be utilized in laboratory experiments?

A: It is best used for experiments requiring efficient moisture removal and in studies focused on drying kinetics and mass transfer rates, especially in chemical engineering and material science lab courses.

Q: Where is this apparatus most commonly used?

A: This fluidized bed dryer is widely used in educational institutions, research labs, and training centers throughout India, particularly within chemical engineering and process technology departments.

Q: What is the main process involved in drying within this apparatus?

A: The process involves heated air passing through a bed of solid particles, causing them to become suspended and fluidized. This maximizes contact between air and solid surfaces, leading to efficient drying and enabling observation of fluidization phenomena.

Q: How does the cyclone separator benefit the apparatus operation?

A: The cyclone separator collects any entrained solid particles carried by the airflow, preventing them from escaping into the environment and ensuring product recovery and laboratory cleanliness.
