FLUID PROPERTIES & HYDROSTATICS BENCH

Get a Price/Quote

MOQ : 1 Piece

FLUID PROPERTIES & HYDROSTATICS BENCH Specification

Frequency
50 Hz

Voltage
220 V AC

Application
Fluid Mechanics Lab Equipment

Automation Grade
Manual

Model No
FM-1001

Temperature Range
5C to 50C

Product Type
FLUID PROPERTIES & HYDROSTATICS BENCH

Feature
Portable,mobile frame, corrosion resistant, robust design

Power Source
Electric

Usage
Fluid Mechanics Lab Equipment

Measurement Range
0 1000 mm water column

Capacity
25 Litres

Core Components
Bench frame, Water tank, Manometer, Measuring cylinders, Accessories

Accuracy
0.5 mm (for scale readings)

Equipment Materials
Stainless Steel, Acrylic, and PVC

Type
Fluid Properties & Hydrostatics Bench

Display Type
Analog

Dimension (L*W*H)
1100 mm x 500 mm x 1200 mm

Weight
Approx 45 kg

Included Accessories
Various measuring cylinders, vernier caliper, hydrometer, U-tube manometer

Water Reservoir Capacity
25 Litres

Working Fluid
Water

Pipe Material
Transparent Acrylic

Mobility
Fitted with castor wheels

Bench Material Finish
Powder-coated

FLUID PROPERTIES & HYDROSTATICS BENCH Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Packaging Details
Carton Box, Export Quality also Available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001, CE

About FLUID PROPERTIES & HYDROSTATICS BENCH

Specification:

FLUIDPROPERTIES & HYDROSTATICS BENCH

The equipment is mounted on asteel-framed bench fitted with castors.

A variety of measuring devices isincorporated either fastened to the back of the bench or free-standing.

Water is stored in a polythene tanksituated on the lower shelf of the bench.

The water can be transferred by twopositive displacement hand pumps either to an elevated open storage tankconnected to a number of glass tubes for free surface studies or to a plasticsink recessed into the working surface so that bench top experiments may beconducted without spillage.

All excess water is returned to thestorage tank via the sink drain.

Robust Design & Construction

Manufactured using premium stainless steel, acrylic, and PVC, the bench is designed for durability and longevity. The powder-coated finish ensures excellent corrosion resistance, making it suitable for prolonged use in educational laboratories where consistent exposure to water and varying temperatures is common.

Comprehensive Experimentation Capabilities

Supplied with a diverse range of accessories including various measuring cylinders, vernier caliper, hydrometer, and U-tube manometer, this bench allows users to conduct experiments on different fluid properties and hydrostatic principles. The transparent acrylic pipe aids in visual observation and analysis during practical sessions.

Ease of Mobility and Operation

A mobile frame fitted with castor wheels enables smooth transportation across laboratory spaces. The bench operates on 220 V AC power and features straightforward manual controls, making it user-friendly for students and instructors alike.

FAQs of FLUID PROPERTIES & HYDROSTATICS BENCH:

Q: How is the bench utilized in a fluid mechanics laboratory?

A: The FLUID PROPERTIES & HYDROSTATICS BENCH is used to perform experiments that demonstrate fluid properties (such as density and viscosity) and principles of hydrostatics. Users can measure, analyze, and observe fluid behavior with supplied accessories and water as the working fluid.

Q: What kinds of experiments can be conducted with the included accessories?

A: The benchs accessoriesmeasuring cylinders, vernier caliper, hydrometer, and U-tube manometerenable students to perform experiments including measuring fluid density, verifying Pascals Law, observing buoyancy, and examining pressure differences across fluid columns.

Q: When is this bench most beneficial for educational purposes?

A: This equipment is especially advantageous for undergraduate or technical laboratory practicals focused on demonstrating and understanding fundamental fluid mechanics concepts. Its robust design allows repeated use during courses and workshops.

Q: Where can the bench be set up within a laboratory?

A: Thanks to its compact footprint (1100 mm x 500 mm x 1200 mm) and castor wheel mobility, the bench can be conveniently positioned wherever required within a laboratory, supporting flexible teaching and experimental setups.

Q: What process is followed to ensure accurate results?

A: To achieve high accuracy (0.5 mm for scale readings), users should calibrate the equipment before use, fill the 25-litre reservoir with water, and follow standard operating procedures during experiments, using the analog display and measuring tools for precise readings.

Q: What are the key benefits of this hydrostatics bench?

A: The bench is portable, corrosion-resistant, and designed for easy operation. Its comprehensive accessory set, robust build, and transparent components foster both effective learning and reliable, long-term laboratory service.
