Flame Photo Meter Digital

Price 100.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Flame Photo Meter Digital Specification

Voltage
230V

Operate Method
Digital Operation with Button Interface

Dimension (L*W*H)
345 x 270 x 195 mm

Color
White and Blue

Classification
Laboratory Instrument

Application
Clinical laboratory, soil testing, food and beverage analysis, pharmaceuticals

Power
230V AC, 50Hz

Material
Metal Body with Powder Coating

Weight
6.5 kg (approx.)

Product Type
Flame Photometer Digital

Usage
Quantitative analysis of sodium, potassium, calcium, and lithium in solution

Capacity
Up to 2 elements simultaneously

Flame Source
LPG (Liquefied Petroleum Gas)

Nebulizer
High efficiency, easy to clean and maintain

Compressor
In-built air compressor

Sample Output
Digital value in ppm or meq/L

Accessories
Air compressor, gas tube, filter set, standard solutions

Calibration
2 point calibration available

Display
Digital LED/LC display for readings

Detection System
Photodetector with interference filters

Element Range
Sodium, Potassium, Calcium, Lithium

Temperature Range
Operating 10C to 40C

Sensitivity
Na - 2 ppm; K - 2 ppm

Filters
Standard Na & K; Optional Ca & Li

Flame Photo Meter Digital Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Flame Photo Meter Digital

DIGITAL FLAME PHOTO METER ETA-13

Edutek are manufacturer and exporter of Digital Flame Photo Meter.

Specification of Digital Flame Photo Meter

No. of Filters Na & K(Ca & Li optional)

Range Na : 0-200 meq/lCa:0-2 meq/l

K : 0-100 meq/lLi: 0-10 meq/l

Sensitivity Na : 5 ppm, Ca:10 ppm

K : 5 ppm,Li : 10 ppm

Read out Dual 2½ digit bright LED Display

Accuracy ± 2% upto 100 meq/l

± 5% above 100 meq/l

Repeatability ± 2 Count.

Detector Silicon Photodiode

Filters Narrow band interference glass

filters

Nebulizer Black bakelite, axial flow type

Flame System LPG and dry oil free air

Warmup time 10 minutes

Power 230V 10% AC 50 Hz

COMPRESSOR UNIT

Air Supply By oil free mini compressor unit with pressure regular

Combustion LPG controlled by precision regulator

Power 230V10%AC50Hz

Accessories instrument with Na & K Filters instruction Manual

* Dust Cover

High-Precision Element Detection

Achieve reliable quantitative analysis for sodium, potassium, calcium, and lithium, thanks to advanced photodetection and interference filters. The digital display allows clear result interpretation, enhancing both accuracy and ease of use in laboratory settings.

Ease of Operation and Maintenance

The intuitive button interface and digital operation provide straightforward sample analysis. The high-efficiency nebulizer is designed for easy cleaning and maintenance, while the in-built air compressor ensures the instrument is always ready for use.

FAQs of Flame Photo Meter Digital:

Q: How does the Flame Photo Meter Digital achieve accurate readings?

A: The instrument uses a high-efficiency nebulizer, photodetector equipped with interference filters, and a digital LED/LC display. This combination ensures precise measurement of sodium, potassium, calcium, and lithium concentrations in various sample solutions.

Q: What is the process for calibrating the Flame Photo Meter Digital?

A: Calibration involves using the 2-point calibration method with standard solutions. Users select appropriate filters and prepare the instrument with the supplied accessories before proceeding with calibration to ensure consistent and precise results.

Q: When should the filters for calcium and lithium be used?

A: Standard filters for sodium and potassium come pre-installed, while filters for calcium and lithium are optional. Install and use the Ca and Li filters when your analysis requires measurement of these particular elements in your samples.

Q: Where can the Flame Photo Meter Digital be applied?

A: This instrument is widely used in clinical laboratories, soil testing facilities, food and beverage quality control labs, and the pharmaceutical industry for assessing element concentrations in solutions.

Q: What are the benefits of using an in-built air compressor in this device?

A: The in-built air compressor simplifies setup, enhances operational stability, and eliminates the need for external air sources. This design increases convenience and supports continuous, reliable measurements.

Q: How is sample output displayed on the device?

A: Sample output is digitally presented, allowing direct reading of concentration values in parts per million (ppm) or milliequivalents per liter (meq/L) on the LED/LC display.
