Five Functions Electric Hospital Bed

Get a Price/Quote

MOQ : 1 Piece

Five Functions Electric Hospital Bed Specification

Accuracy
100 % %

Power Source
Electric Powered (AC supply)

Capacity
250 kg Kg

Frequency
50-60 Hz Hertz (HZ)

Automation Grade
Automatic

Feature
Highly Efficient

Model No
FIVE-FUNCTIONS-EB-3036064

Core Components
Electric Motor, Wheels, Remote Control, Steel Frame, ABS Parts

Voltage
220V AC Volt (v)

Equipment Materials
Mild Steel Frame, ABS Side Rails and Head/Foot Boards

Type
Five Functions Electric Hospital Bed

Usage
Laboratory

Display Type
Digital Remote Control

Dimension (L*W*H)
2150 x 950 x 500 mm Millimeter (mm)

Weight
Approx 110 kg Kilograms (kg)

Safety Features
Battery backup optional, Overload Protection

Anti-Trendelenburg
0 to 12

Control Option
Handheld Remote

Head/Foot Board
ABS removable

Mattress Platform
Four section powder coated steel

Height Adjustment
500 mm to 750 mm

Knee Rest Adjustment
0 to 35 electrically adjustable

Castors
125 mm diameter with braking system

Finish Type
Epoxy Powder Coated

Backrest Adjustment
0 to 75 electrically adjustable

Motor Type
DC Linear Actuator

Trendelenburg Position
0 to 12

Side Railings
Collapsible ABS

About Five Functions Electric Hospital Bed

Five Functions Electric Hospital Bed

Edutek are leading manufacturer and Exporter of Hospital Beds - Five Function Electric Bed, Three Function Electric ICU Bed, Three Function Mechanical ICU Bed and Double Function Manual Bed.

Specification of Five Functions Electric Bed

All parts are made by tooling to ensure uniform quality.
Integrated stamping frame and mattress base are steel made with epoxy. Polyester powder coated& baked finish,
resistant to chipping and scratching;
Bed head/foot boards are made of ABS plastic, washable and removable.
L2120*W970*H450-700mm

Functions of Five Functions Electric Bed

Angle of back section: 0 ~ 80 (5)
Angle of leg section: 0 ~ 40(5)
Adjustable height: 450-700mm
Angle of Trendelenburg and reserve Trendelenburg: 0 ~ 13(2)

Accessory of Five Functions Electric Bed

Four pieces individual PP siderails, embed design hand-set, easy to operate.
Taiwan Linkan actuator, CE approved and quiet operation.
ABS headboard and footboard
1pc control box, 1pc handset
5" central control castors.
Two sectional I.V pole;

Precision Electric Adjustments

Effortless adjustment of backrest, knee rest, height, and inclines is ensured by DC linear actuators managed through a digital remote control, allowing staff or patients to fine-tune for comfort and medical needs. The reliable mechanism prioritizes both safety and accuracy at all times.

Robust Construction and Mobility

Crafted from a mild steel frame and four-section powder-coated platform, the bed provides lasting durability. ABS side rails and head/foot boards are removable for convenience, while 125 mm castors with a braking system guarantee smooth maneuverability and stable placement when needed.

Safety Innovations and User Advantages

Designed for high efficiency and reliability, this bed features overload protection and optional battery backup. The collapsible ABS side railings help prevent falls, and the maximum load capacity reaches 250 kg. Each function can be activated with ease using the handheld digital remote, ensuring safe and comfortable care.

FAQs of Five Functions Electric Hospital Bed:

Q: How do I adjust the backrest or knee rest on the Five Functions Electric Hospital Bed?

A: Adjustments to the backrest (0 to 75) and knee rest (0 to 35) are performed electrically via the handheld digital remote control. Simply press the corresponding button to achieve the desired angle, supporting patient comfort and medical positioning requirements.

Q: What safety features are included in this hospital bed?

A: This bed is equipped with collapsible ABS side railings for fall prevention, overload protection to safeguard internal components, and an optional battery backup for continued operation during power loss. The braking system on the castor wheels ensures stationary safety when needed.

Q: When is it suitable to use the Trendelenburg or Anti-Trendelenburg positions?

A: The Trendelenburg (0 to 12) and Anti-Trendelenburg (0 to 12) positions are primarily used for specific clinical scenarios, such as improving circulation or facilitating certain procedures. These positions can be set using the remote control for instant patient adjustment.

Q: Where can the Five Functions Electric Hospital Bed be installed and used?

A: This bed is suitable for hospitals, clinics, and laboratory environments. Its automated adjustments, robust build, and mobility features make it ideal for patient wards, ICUs, or any healthcare setting requiring reliable, adaptable support equipment.

Q: What process should be followed to maintain the beds optimal performance?

A: Routine cleaning with appropriate disinfectants, regular inspection of electrical components, and checking the braking system and battery backup will help maintain the beds efficiency. Additionally, periodic lubrication and prompt attention to any abnormal operation are recommended.

Q: How does the bed benefit medical staff and patients?

A: Automated adjustments reduce manual handling for caregivers, enhancing workflow and safety. For patients, precise positioning and easy mobility provide greater comfort, support, and dignity during treatment or recuperation.
