EXPANSION INDEX TEST APPARATUS

Get a Price/Quote

Product Details:

Measurement Range Defined by gauge sensitivity
Warranty 1 year
Feature Measures soil expansion index
Model No EDEX-SACT-49
Automation Grade Manual
Accuracy High precision gauge-enabled readings
Temperature Range Ambient conditions
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

EXPANSION INDEX TEST APPARATUS Product Specifications

Core Components Brass Stainless Steel
Power Source Not required (manual operation)
Usage Soil testing applications
Dimension (L*W*H) Compact
Equipment Materials Brass Stainless Steel
Automation Grade Manual
Accuracy High precision gauge-enabled readings
Temperature Range Ambient conditions
Model No EDEX-SACT-49
Weight Lightweight and portable
Type Expansion Index Testing Apparatus
Feature Measures soil expansion index
Display Type Dial Display
Warranty 1 year
Measurement Range Defined by gauge sensitivity

Product Description

EXPANSION INDEX TEST APPARATUS

Use: determining the expansion index of soils.

Standard: ASTM D-2435, D-4546; AASHTO T-216.

Specifications:

Construction The unit consists of a cast aluminum base and collar, stainless steel specimen ring
Base and Collar. Cast aluminum construction; brass hold-down rods.
Specimen Ring. Stainless steel; 101.6 x 25.4 mm (4" internal diam. x 1" h.).
Porous Stones. 101.4 x 12.7 mm (4" diam. x 1/2" thick).
Loading Weight. Brass; 5.7 kg (12.6 lbs.).
Dial Indicator: 0.3" range x 0.0001" graduations. 8 mm range x 0.002 mm graduations.
Test Duration. 24 hours or less on cured sample.

FAQs of EXPANSION INDEX TEST APPARATUS:

Q: What is the measurement range of the Expansion Index Test Apparatus?

A: The measurement range of the Expansion Index Test Apparatus is defined by gauge sensitivity.

Q: What is the power source requirement for the Expansion Index Test Apparatus?

A: The Expansion Index Test Apparatus does not require a power source as it operates manually.

Q: What is the warranty period for the Expansion Index Test Apparatus?

A: The Expansion Index Test Apparatus comes with a warranty period of 1 year.

Q: What type of display does the Expansion Index Test Apparatus have?

A: The Expansion Index Test Apparatus features a dial display for easy monitoring.

Q: What are the core components and equipment materials used in the Expansion Index Test Apparatus?

A: The core components and equipment materials of the Expansion Index Test Apparatus are made of brass and stainless steel, ensuring durability and reliability for soil testing applications.
