Digital Spectrophotometer

Get a Price/Quote

MOQ : 1 Piece

Digital Spectrophotometer Specification

Dimension (L*W*H)
320 mm x 220 mm x 130 mm

Capacity
Single Cell Holder

Product Type
Digital Spectrometers

Usage
Digital Spectrometers is an economical, reliable Rugged and most accurate system for spectrophotometric anylsis of any concentration. It operates at a wavelength range of 340 to 960 nm. Its output is available on 31/2 digital LED display is provided for wave length.

Material
ABS Plastic and Metal

Color
White

Operate Method
Digital Control Panel

Classification
Analytical Laboratory Instrument

Weight
4.5 kg

Voltage
230 V AC

Application
Spectrophotometric analysis for laboratory and research purposes

Power
12 W

Display Type
3½ Digit LED Digital Display

Spectral Bandwidth
5 nm

Operating Temperature
10°C to 40°C

Power Supply Frequency
50 Hz

Transmittance Range
0-100% T

Accuracy
±2% T

Interface
No Connectivity (Standalone)

Sample Holder
Standard 10 mm path length cuvette

Detector Type
Photodiode

Wavelength Range
340 nm to 960 nm

Resolution
1 nm

Light Source
Tungsten-halogen lamp

Digital Spectrophotometer Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Digital Spectrophotometer

Digital Spectrophotometer

Digital Spectrometers is an economical, reliable Rugged and most accurate system for spectrophotometric anylsis of any concentration. It operates at a wavelength range of 340 to 960 nm. Its output is available on 31/2 digital LED display is provided for wave length.

MODEL	ET-31	ET-38
Range	340 to 960 nm	340 to 960 nm
Resolution	0.1%T, 0.001 Abs	0.1%T, 0.001 Abs
Output	%T: 0 to 100%, Abs; 0 to 1.999, Conc: 0 to 1999	%T: 0 to 100%, Abs; 0 to 1.999, Conc: 0 to 1999
Detector	Silicon Photo diode	Silicon Photo diode
Light source	6V l Amp. Vertical Tungsten Halogen Lamp	6V l Amp. Vertical Tungsten Halogen Lamp
Monochromate	600 Lines / mm grating	600 Lines / mm grating
Path length	10 mm	50 mm
Spectral bandwidth	10 mm	10 mm
Wave length resolution	5 nm - 1 nm	5 nm - 1 nm
Wave length accuracy	2.5 nm	2.5 nm
Repeatability	±2 nm ±1 nm	±2 nm ±1 nm
Display	3 ½ digit LED Dual Display	3 ½ digit LED Dual Display
Operating temp.	5 to 45°C	5 to 45°C
Power range	230V ±10% AC, 50 Mz	230V ±10% AC, 50 Mz
Dimensions	490 x 300 x 165 mm	490 x 300 x 165 mm
Weight	8.5 Kg (Approx)	8.5 Kg (Approx)
Accessories	10 Test tubes (12mm dia)	10 Test tubes (12mm dia)
	Dust Cover	Dust Cover
	Operation Manual	Operation Manual

Reliable Analysis Across a Broad Wavelength Range

This digital spectrophotometer enables accurate analysis over a spectrum from 340 nm to 960 nm, making it suitable for diverse analytical laboratory tasks. The instrument maintains strong performance due to its advanced light source, photodiode detector, and precise bandwidth, ensuring dependable measurements for various sample types. Laboratories benefit from its versatility and cost-effectiveness for day-to-day spectrophotometric work.

Intuitive Operation and Clear Results

With its simple digital control panel and bright 3 digit LED display, the spectrophotometer offers user-friendly operation. Setup and measurement processes are streamlined, reducing training time and potential for error. The standalone design requires no external connectivity, making it ideal for laboratories seeking a rugged, low-maintenance analytical tool that consistently delivers clear, easy-to-read results.

FAQs of Digital Spectrophotometer:

Q: How is the Digital Spectrophotometer operated?

A: The instrument is controlled via a digital panel, allowing straightforward selection of measurement parameters and display of results on the 3 digit LED display for clear data visualization.

Q: What types of samples can be analyzed with this spectrophotometer?

A: You can use standard 10 mm path length cuvettes, making it suitable for liquid samples commonly encountered in analytical, educational, and research laboratories.

Q: Where is the Digital Spectrophotometer most effectively used?

A: This spectrophotometer is designed for analytical laboratory and research environments, including universities, research centers, and industrial quality control labs.

Q: When should this model be chosen over other spectrophotometers?

A: It is ideal when an economical, reliable, and accurate system is required for routine spectrophotometric analyses, especially where standalone operation is preferred.

Q: What is the process for conducting a measurement with this spectrophotometer?

A: Place your sample in the standard 10 mm cuvette holder, set the desired wavelength via the control panel, and read the transmittance result directly from the LED display.

Q: How does the instrument benefit laboratory workflows?

A: Its robust yet compact build, rapid setup, and precise digital readings streamline routine analyses, minimizing downtime and supporting efficient work habits.

Q: What are the main benefits of the standalone configuration?

A: With no connectivity needed, the spectrophotometer increases portability and reduces complexity, making it especially beneficial for labs requiring reliable, independent operation.
