Cryo Bath

Get a Price/Quote

MOQ : 1 Piece

Cryo Bath Specification

Automation Grade
Semi-Automatic

Accuracy
100 % %

Temperature Range
-10 C to +60 C Celsius (oC)

Voltage
220 V Volt (v)

Measurement Range
-10 C to +60 C

Frequency
50 Hz Hertz (HZ)

Core Components
Compressor, Temperature Sensor, Heater, Circulation Pump

Capacity
4.5 Ltrs Ltr

Feature
Highly Efficient

Power Source
Electric

Equipment Materials
Stainless Steel (Inner Chamber), Powder Coated Steel (Outer Body)

Type
Cryo Bath

Usage
Laboratory

Display Type
Digital

Dimension (L*W*H)
430 x 330 x 380 mm Millimeter (mm)

Weight
22 Kg Kilograms (kg)

Safety Feature
Over Temperature Protection, Low Liquid Level Alarm

Controller Type
PID Digital Controller

Bath Fluid Compatibility
Water, Alcohol, Glycol Mixture

Application
Biological, Chemical, Industrial Research

Operating Ambient Temperature
5C to 40C

Noise Level
<50 dB

Heating/ Cooling Rate
2C/min

Insulation
Polyurethane Foam

Circulation Type
Internal/External

About Cryo Bath

Cryo Bath

Double walled construction with inner S.S. argon welded one piece pot which avoids leakages.
2" Thick Insulation ensures stable temperature with reduced energy consumption.
CFC Free hermitically sealed Emerson Copeland make compressor for better cooling with R 134 A (Eco friendly) refrigerant with time delay to safe guard compressor.
Circulation pump is provided for better uniformity of Temperature instead of stirrer.
Side mounted circulating pump 15 ltr. /min capacity, single phase, 230 Volts.
Top mounted removable lid.
S.S. Tubular heater (water immersion type) is used at bottom for better heat distribution.

Temperature Control :-

By means of Imported Microprocessor based auto tuned PID controller with CE mark & dual display of set value & process value.

Safety Features:-

Safety audio visual alarms for temperature overshoot & undershoot.
Compressor ON delay timer (2 min.) to safe guard the compressor.

Optional :

Digital temp. indicator-cum-controller with computer data logger.

Advanced Temperature Regulation

The CB-4.5 Cryo Bath employs a highly responsive PID digital controller, delivering rapid and accurate temperature adjustments between -10C and +60C. With a heating and cooling rate of 2C per minute, users can quickly achieve and maintain desired thermal conditions for diverse laboratory protocols, ensuring experiment integrity.

Robust Construction and Safety Features

Constructed with a stainless steel inner chamber and powder-coated steel outer body, the cryo bath offers durability alongside efficient insulation through polyurethane foam. Its safety mechanisms, such as over temperature protection and low liquid level alarm, safeguard both operators and experiments, making the device reliable for regular use in sensitive laboratory environments.

Versatile Bath Fluid Compatibility

The CB-4.5 accommodates water, alcohol, and glycol mixturesallowing researchers flexibility depending on application requirements. Internal and external circulation options further enhance fluid management, supporting optimal temperature uniformity across biological, chemical, and industrial research tasks.

FAQs of Cryo Bath:

Q: How does the Cryo Bath ensure precise temperature control?

A: The Cryo Bath maintains precise temperature regulation using a PID digital controller which continuously monitors and adjusts the heating or cooling process for accuracy within the -10C to +60C range.

Q: What safety features are included in the cryo bath?

A: Safety is assured with over temperature protection and a low liquid level alarm, preventing potential hazards and preserving sample integrity during operation.

Q: When should I use water, alcohol, or glycol mixture as the bath fluid?

A: Water is suitable for most standard applications, while alcohol or glycol mixtures are recommended for temperatures below freezing or scenarios requiring enhanced thermal stability. Selection depends on specific research or industrial requirements.

Q: Where can the Cryo Bath be used?

A: This model is suited for laboratories engaged in biological, chemical, or industrial research and is commonly exported, manufactured, and supplied across India.

Q: What is the process for setting the desired temperature?

A: Simply use the digital display and PID controller on the unit to enter your required temperature. The cryo bath rapidly adjusts to your set point at a rate of 2C per minute, indicated clearly on the digital screen.

Q: How does the insulation benefit laboratory operations?

A: Polyurethane foam insulation ensures minimal heat exchange with the environment, promoting efficient operation, energy conservation, and stable temperatures during extended laboratory procedures.

Q: What makes the Cryo Bath highly efficient and accurate?

A: Its combination of PID digital control, rapid heating/cooling rates, reliable insulation, and robust components ensure 100% temperature accuracy, supporting consistent and reproducible experimental outcomes.
