Compression Testing Machine (Electrically Cum Hand Operated-Three Gauges)

Price 100.0 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

Compression Testing Machine (Electrically Cum Hand Operated-Three Gauges) Specification

Warranty
1 Year

Accuracy
100 %

Features
hydraulic, electrically operated

Phase
415 Volts, 3-ph or 230 Volts, 1-ph A.C.

Voltage
415 Volt (v)

Power
230 Volt (v)

Material
iron

Compression Testing Machine (Electrically Cum Hand Operated-Three Gauges) Trade Information

Minimum Order Quantity
10 Pieces

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Compression Testing Machine (Electrically Cum Hand Operated-Three Gauges)

Compression Testing Machine

Edutek are leading manufacturer and exporter of Compression Testing Machines Analogue, Digital, Micro Processor Based, Servo Controlled and Automatic Compression Testing Machines Compression Testing Machines Series Compression Testing Machines are the finest of their types available.
Compression Testing Machine Electrically cum Hand Operated-Three Gauges

This is a hydraulic, electrically operated unit, designed for conducting compression tests on concrete specimens up to 20 cm. Diameter (or width and depth) and 30 cm, in height and also rocks and various other materials. Cold Crushing Strength test is also possible.
The machine consists of a steel cross head and cast iron base with two pillars connecting the base and cross head by means of nuts. The hydraulic jack is fixed to the base. The upper platen has got a self aligning action and is attached to a screw which passes through the cross head and can be raised or lowered for initial clearance adjustment. The lower platen rests on the jack ram and is positioned with the help of a centering pin.
Loading is accomplished by the upward movement of the with the help of a centering pin. Loading is accomplished by the upward movement of the motorized pumping unit is of plunger type and is connected to the jack by means of a steel connecting tube.
A maximum red pointer is provided to facilitate taking of the readings after failure of specimens. The pressure gauges of 20 cm diameter with isolating valves are fixed on the pumping unit at an angle for easy readability..
The machine is fitted with control which enables the rate of application of load to be varied. The machine is equipped with facilities for hand operation as well.
The electrical pumping unit is fitted with three micro switches one for each pressure gauge and will switch off the machine automatically as the load on the machine approaches its full capacity of the gauge in case the isolating valves are not operated. This will protect the pressure gauges and the whole unit so that in case of break down of power supply, the machine will stop and will not restart unless the starting switch is operated.
The machine satisfies the essential specifications of Indian Standard No. 516-1959. For operation on415 Volts, 3-ph or 230 Volts, 1-ph A.C.

Precision Testing for Maximum Reliability

This advanced machine delivers highly accurate compression test results, facilitated by its triple-gauge configuration and hydraulic system. The electrical and hand-operated options ensure versatility for various sample types, supporting applications across construction, engineering, and material science sectors.

User-friendly and Versatile Operation

Designed for easy integration, the machine works on both 230 V single-phase and 415 V three-phase AC power. The robust hand-operated alternative is ideal for remote or energy-limited environments, making it suitable for diverse laboratories, workshops, and field locations.

Built with Durability and Efficiency in Mind

Crafted from high-quality iron and equipped with a hydraulic mechanism, the machine ensures longevity, operational stability, and repeatable precision. Its comprehensive one-year warranty provides additional peace of mind for buyers seeking long-term value.

FAQs of Compression Testing Machine (Electrically Cum Hand Operated-Three Gauges):

Q: How is the compression testing process conducted with this machine?

A: To perform a compression test, place the specimen onto the loading platform, set the required power supply (230 V or 415 V), and initiate the hydraulic system. The operator may choose between electric or manual modes, and test readings are monitored using the three integrated gauges for optimal accuracy.

Q: What materials can be tested using this compression testing machine?

A: The machine is designed to test a wide variety of materials, including concrete, cement, bricks, and other building materials. Its high-pressure capability and precise gauges make it suitable for comprehensive strength assessment in laboratory and industrial environments.

Q: When should the electrically operated mode be used instead of the hand-operated mode?

A: Electrically operated mode is preferable when continuous or high-volume testing is needed, reducing manual effort and increasing throughput. The hand-operated function is ideal in situations where power supply is limited or field testing is required.

Q: Where is this machine most commonly installed or used?

A: This compression testing machine is typically installed in civil engineering labs, construction material testing centers, quality assurance departments, and educational institutions. Its flexibility allows it to be used both in permanent laboratory setups and at remote field sites.

Q: What benefits does the triple gauge system provide during testing?

A: The inclusion of three gauges enhances precision, enables simultaneous monitoring of pressure parameters, and ensures immediate detection of discrepancies, thereby increasing the reliability and trustworthiness of test results.

Q: What warranty support is offered with this compression testing machine?

A: The manufacturer provides a one-year warranty, covering manufacturing defects and ensuring maintenance support for buyers. This ensures hassle-free operation and assistance during the initial period after purchase.

Q: Is installation and training provided by the exporter or supplier in India?

A: Indian exporters, manufacturers, and suppliers typically offer comprehensive installation services and operational training, helping clients properly set up and use the machine for accurate and safe compression testing.
