Compact Digital Universal Tester

Price 1000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Compact Digital Universal Tester Specification

Weight
Approx. 120 kg

Color
Off-white/Blue (as per manufacturers image)

Capacity
5 kN

Sensor
High-precision load cell

Dimension (L*W*H)
600 mm x 400 mm x 1450 mm

Machine Speed
0.01 - 500 mm/min

Control System
Microprocessor based digital control

Power
220V AC, 1 Phase, 50 Hz

Operating Temperature
10C to 45C

Features
Digital display, Programmable controls, Overload protection, Data export

Power Source
Electric

Product Type
Compact Digital Universal Tester

Voltage
220V AC

Load Capacity
5 kN (kilonewtons)

Accuracy
1% of indicated load

Stroke Length
Up to 800 mm

Speed Range
0.01 mm/min to 500 mm/min

Resolution
0.01 mm (displacement), 0.001 kN (load)

Screw Size
Lead screw, 20 mm dia

Power Consumption
1.5 kW

Frequency
50 Hz

Application
Tensile, Compression, Flexural, Shear, Peel Tests on Materials

Phase
Single Phase

Automatic Grade
Semi-Automatic

Material
Mild steel, powder coated

Display Type
Digital LCD/LED Display

Drive System
Servo motor driven mechanism

Crosshead Travel
800 mm max

Test Modes
Tensile, Compression, Flexural, Peel, Shear

Data Storage
Inbuilt memory for test data

Data Output
USB/RS232 interface for PC connectivity

Software Support
PC software for analysis and reporting

Grips Provided
Standard wedge grips (Optional grips for other tests)

Noise Level
< 60 dB (Operational)

Safety
Emergency stop and overload protection

Testing Standards
Complies with ASTM, ISO, and BIS standards

Compact Digital Universal Tester Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Compact Digital Universal Tester

Compact Digital Universal Tester

The tester offers excellent accuracy and ease of use. It is strong and durable enough to withstand many years of use, yet it has a compact load frame that provides greater flexibility of placement. Whether you choose the basic unit or add the optional attachments/grips, the tester sets the standard in universal testing.
The load cell used in this tester offer one-touch zero adjustment and load cell capacity discrimination guarantees accuracy and speeds the setup process.
Loading Accuracy as high as + 1% Variable Straining Speeds
The basic frame allows a total jaw separation of 700 mm. However, extended frame having jaw separation up-to 2000 mm may be supplied at additional cost.
The machine is operated on 230 volts. 1-ph, 50 c/s or 440 volts,3-ph,50 c/s Mains or as desired. A comprehensive range of grips, attachments/fixtures, cutting dies are available to suit the testing needs of many different industries.
Capacities available: 20 Kgf to 10000 Kgf

High-Precision Testing Across Multiple Modes

The tester facilitates diverse mechanical testing, including tensile, compression, flexural, shear, and peel modes. With a stroke length of up to 800 mm and resolution down to 0.01 mm (displacement) and 0.001 kN (load), it delivers accuracy and flexibility for varied material analyses. Standard wedge grips are provided, with optional grips available for specialized tests.

Digital Interface and Advanced Data Management

Equipped with a digital LCD/LED display, the tester offers clear results and programmable controls for seamless operation. Data can be exported via USB/RS232 interface, while inbuilt memory ensures that test results are securely stored. Dedicated PC software supports comprehensive analysis and reporting, enhancing productivity in laboratory and industrial environments.

Safety and Reliability in Operation

Designed with user safety in mind, emergency stop and overload protection mechanisms are standard. The semi-automatic, microprocessor-based control system stabilizes performance, keeping operational noise under 60 dB. Complying with globally recognized standards (ASTM, ISO, BIS), the machine ensures robust and repeatable test outcomes for diverse applications.

FAQs of Compact Digital Universal Tester:

Q: How does the Compact Digital Universal Tester ensure user safety during operation?

A: The tester incorporates emergency stop and overload protection features to safeguard operators and samples. These safety mechanisms prevent damage by immediately halting operation in case of abnormal conditions, ensuring a secure testing environment.

Q: What types of material tests can be performed with this tester?

A: It supports tensile, compression, flexural, shear, and peel tests, making it suitable for analyzing various physical properties of metals, polymers, composites, and other materials, across both industrial and research applications.

Q: When should optional grips be considered for testing?

A: Optional grips are recommended when you are performing specialized tests that require unique holding configurations beyond the scope of standard wedge grips provided. This ensures optimal sample compatibility and accurate results.

Q: Where can the test data be stored and exported from the tester?

A: Test results are saved in the testers inbuilt memory, and can also be exported directly to a PC via USB or RS232 interface. This facilitates data analysis, reporting, and archiving using the supported PC software.

Q: What process does the tester use to ensure accurate load measurement?

A: High-precision load cells and microprocessor-based digital controls are utilized, delivering accuracy within 1% of the indicated load. Coupled with programmable controls, this ensures every measurement is both consistent and reliable.

Q: How does this tester benefit laboratory and industrial users?

A: Its compliance with ASTM, ISO, and BIS standards, along with programmable controls and comprehensive software support, enables efficient test cycles, rigorous data analysis, and reliable reporting, streamlining materials research and quality assurance processes.
