Co2 Incubator

Price 5.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Co2 Incubator Specification

Capacity
160 Liters

Product Type
CO2 INCUBATOR

Operate Method
Digital Control Panel

Usage
Scientific & Laboratory Instruments

Classification
Laboratory Equipment

Color
White

Dimension (L*W*H)
50 x 50 x 80 cm

Weight
Approx. 60 kg

Voltage
220 Volt (v)

Material
Stainless Steel (Inner), Powder Coated Steel (Outer)

Application
Scientific & Laboratory Instruments

Power
600 W

Co2 Incubator Trade Information

Minimum Order Quantity
1 Piece

Packaging Details
carton box, export quality also available

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Co2 Incubator

Carbon dioxide (CO2) incubators provide optimal growing conditions and contamination prevention for valuable cell cultures.
EDUTEK provides a wide range of CO2 incubators, ranging from a small capacity and volume to a large-scale capacity cabinet. All the
CO2 incubators are built with the patented Water Jacket and Air Jacket systems, which minimizes the risk of condensation at the present and in the future.
Water tank for humidity in the chamber.
Air jacket: Equipped with UV Lamp for sterilizing.
Water jacket: equipped with HEPA filter.
Equipped with USB port and LCD Display, the incubator can save data in real time.
High quality CO2 gas filter ensures the inside gas quality.
SMC brand gas circuit valves ensure more stable CO2 concentration and less consumption of CO2 gas.
Microcomputer controller, LED displays temperature, CO2 concentration, run-time and timing.
High quality infrared sensor for accurate CO2 concentration.
The working chamber adopts round angle structure, easy to clean.
Capacity: 160L
Heating: Air Jacket, Water Jacket
Temp. Range: RT +5 60C
Control Type: Microcomputer Controller
Temp. Fluctuation: < 0.2C (at 37C)
Temp. Uniformity: < 0.2C (at 37C)
Time Setting: 999h or Continuous
Alarm: Audible & Visible Alarm; Over Temp. alarm; CO2 Concentration alarm
Shelves: 2 pcs/ Adjustable
Material: External cold-rolled steel with painting: Internal Stainless-steel
Door: With Inner door & External door
CO2 Range: Infrared sensor, range 0-20%
CO2 Control Resolution: 0.10%
Humidification Type: Water Tank for normal evaporation
Sterilization Type: UV Lamp for Air jacket
Ambient Temp. & Humidity: 18-30C, Suggest 2 2C; Relative humidity < 80%
Caster: Footmaster caster
Consumption: 650W, 1000W
Power Supply: AC 110/220V 10%, 50/60Hz
Air Jacket:
Internal Size (WXDXH)mm: 498x546x678
External Size (WXDXH)mm: 700x666x1101
Packing Size (WXDXH)mm: 790x830x1250
Gross Weight(kg): 109
Water Jacket:
Internal Size (WXDXH)mm: 498x480x722
External Size (WXDXH)mm: 747x654x1260
Packing Size (WXDXH)mm: 780x880x1420

Why Choose This CO2 Incubator?

Engineered for reliability and accuracy, this CO2 incubator is ideal for a variety of laboratory applications, including cell culture and microbiology research. The spacious 160-liter chamber, adjustable shelving, and precise digital control panel allow for easy customization of the internal environment. Efficient safety mechanisms and user-friendly features make it a preferred choice for laboratories requiring dependable performance.

Enhanced Safety and Monitoring Features

With over-temperature protection and a door open alarm, this incubator prioritizes sample security. The LED digital display enables real-time monitoring of temperature, humidity, and CO2 levels, minimizing the risk of errors. Transparent inner glass doors and interior lighting further support continuous visual inspection without disturbing the incubators internal atmosphere.

FAQs of Co2 Incubator:

Q: How does the infrared (IR) CO2 sensor benefit laboratory processes?

A: The infrared (IR) CO2 sensor provides precise and stable monitoring of CO2 levels within the incubator. This accuracy is crucial for applications such as cell culture, ensuring consistent conditions that lead to reliable experimental results.

Q: What steps are involved in setting up and operating the CO2 incubator?

A: To operate the incubator, connect to a 220V power source, set desired temperature, humidity, and CO2 levels using the digital control panel, and fill the water tray for humidification. Place samples on the adjustable shelves and monitor conditions via the LED digital display.

Q: When should the over-temperature protection mechanism be checked?

A: It is recommended to verify the over-temperature protection feature during installation, routine maintenance, and before running critical experiments. Regular checks ensure the system will safeguard samples in the event of unexpected temperature increases.

Q: Where can this CO2 incubator be optimally installed?

A: This incubator is best suited for laboratories engaged in scientific research or clinical diagnostics. It should be placed in a clean, stable environment with adequate space for ventilation and easy access to the digital controls and door for sample loading.

Q: What is the benefit of having a transparent inner glass door with a magnetic outer seal?

A: The transparent inner glass door allows for visual inspection of cultures without opening the chamber, preserving the internal environment. The magnetic outer door seal ensures a tight closure, reduces contamination risk, and maintains temperature and CO2 stability.

Q: How does humidity control enhance laboratory experiments?

A: Controlled humidity, up to 95% RH with a water tray, helps protect delicate biological samples from desiccation. This fosters optimal cell growth conditions and increases reproducibility in experiments involving living organisms.

Q: Can this incubator be used for processes beyond cell culture?

A: Yes, the temperature and CO2 control make it suitable for diverse laboratory applications, including drug testing, microbiological studies, and tissue engineering, supporting scientific research across disciplines.
