CLIPPING & CLAMPING CIRCUIT APPARATUS

Price 50.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

CLIPPING & CLAMPING CIRCUIT APPARATUS Specification

Power Supply
230V 10% AC, 50 Hz

Operating Temperature
0C to 50C

Resolution
Analog, dependent on test instrument/oscilloscope used

IP Rating
Not Rated (Laboratory instrument)

Display Type
No display, test points for oscilloscope connection

Features
Simple circuit design, rugged construction, easy-to-use for basic laboratory experiments.

Output
Clipped or clamped waveform via output terminals

Input
Sine, Square, or DC input signals via external function generator (not included)

Power Source
Mains powered (AC 230V 10%)

Components
Includes diodes, resistors, capacitors, test points, and connection leads

Usage
ENGINEERING ELECTRONICS INSTRUMENTS

Response Time
Instantaneous, depends on circuit components

Interface
Banana sockets/test points for input and output

Product Type
CLIPPING & CLAMPING CIRCUIT APPARATUS

Application
ENGINEERING ELECTRONICS INSTRUMENTS

Rated Voltage
230V AC

Supply Voltage
230V AC

Size
Standard instrument box (approx. 25 cm x 18 cm x 8 cm)

Dimension (L*W*H)
250 x 180 x 80 mm

Function
Demonstrates the working of both clipping and clamping circuits using standard electronic components.

Color
Blue/Black (As in image)

Weight
Approx. 1.3 kg

Current Rating
<50 mA (Operating current)

Thickness
Approx. 3 mm panel thickness

Capacity
Suitable for dual circuit experiments

Frequency
50 Hz operation (mains frequency)

About CLIPPING & CLAMPING CIRCUIT APPARATUS

Specification:

CLIPPING & CLAMPING CIRCUIT APPARATUS

Description:

Instrument Comprises of DC regulated power supply 0-3 V DC / 150 mA, Two fix output DC power supplies connected in series of diodes for positive & negative clipping, circuit diagram for clipping & clamping circuit is engraved on front panel components placed inside & connections brought out at 4mm sockets.

Versatile Educational Instrument

Optimized for classroom and laboratory use, this apparatus supports dual experiments for clipping and clamping circuits. It provides hands-on experience with analog waveform manipulation, an essential aspect of electronics engineering. Its standard-sized, rugged panel ensures endurance while facilitating demonstration and laboratory training sessions.

User-Friendly Design and Safety

Constructed for easy handling, the unit includes visible test points and banana sockets for swift connectivity. Over-current protection via a fused input means students and instructors can work safely. The rotary selector switch allows effortless change between circuit configurations, minimizing setup time and maximizing efficiency.

Compatible Waveforms and Reliable Output

Designed to accept sine, square, or DC waveforms through a function generator, the apparatus reliably demonstrates clipped and clamped outputs at designated terminals. It accommodates oscilloscope connections, enabling real-time visualization of waveforms and immediate learning of underlying circuit principles.

FAQs of CLIPPING & CLAMPING CIRCUIT APPARATUS:

Q: How does the Clipping & Clamping Circuit Apparatus demonstrate both circuit types?

A: The apparatus is equipped with a rotary selector that allows users to switch between series and parallel clipping or clamping circuit configurations. Standard electronic components manipulate input waveforms, displaying either clipped or clamped outputs at the corresponding test points.

Q: What safety features are integrated into this apparatus?

A: A fused input rated at 500 mA provides over-current protection, safeguarding both users and the equipment during operation. The robust powder-coated metal panel further enhances user safety and product durability.

Q: When should this apparatus be used in an electronics laboratory?

A: It is ideally employed during foundational electronics courses to illustrate and analyze waveform modification techniques. It can also be used in experiments or demonstrations requiring real-time observation of clipped or clamped waveforms on an external oscilloscope.

Q: Where are the input and output connections made for this apparatus?

A: Inputs for sine, square, or DC signals are made via banana sockets on the front panel, typically from an external function generator. The corresponding outputs, including clipped or clamped waveforms, are accessed through dedicated banana jacks/test points for easy oscilloscope connection.

Q: What is the main benefit of using this apparatus in electronics training?

A: It provides a clear, hands-on method to visualize and compare the effects of clipping and clamping circuits on analog waveforms. This enhances conceptual understanding and practical skills for students and professionals in electrical engineering.

Q: How do you configure a desired circuit on this trainer?

A: Selection is made via the rotary switch, which changes the circuit path and associated components based on the chosen clipping or clamping mode. The instruction manual guides users step-by-step through all possible configurations and connections.

Q: What accessories and components are included with the apparatus?

A: The unit comes with a set of connecting leads and an instruction manual. The panel is populated with essential components like diodes, resistors, and capacitors, allowing immediate experimentation without the need for additional parts.
