CLASS C RF TUNED AMPLIFIER

Name: CLASS C RF TUNED AMPLIFIER
Brand: EDUTEK INSTRUMENTATION
Price: 1200.0 INR
Availability: InStock

Price 1200.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

CLASS C RF TUNED AMPLIFIER Specification

Usage
ENGINEERING ELECTRONICS INSTRUMENTS

Power Supply
External DC Supply

Components
Transistors, Tuned tank circuit, Capacitors, Inductors

Operating Temperature
0C to 55C

Interface
RF connectors: BNC/SO-239

IP Rating
IP20

Output
10W to 50W (depending on model)

Thermal Conductivity
Aluminum heatsink for thermal dissipation

Power Source
DC Powered

Features
High efficiency, Small form factor, Tuned tank circuit for selectivity

Display Type
No Display

Input
RF Input: 1 mW to 100 mW

Response Time
<1 s

Product Type
CLASS C RF TUNED AMPLIFIER

Application
ENGINEERING ELECTRONICS INSTRUMENTS

Rated Voltage
12V DC

Supply Voltage
+12V to +15V DC

Size
Standard: 180 mm x 80 mm

Dimension (L*W*H)
180 mm x 80 mm x 50 mm

Function
Amplifies RF signals, designed for Class C operation

Color
Metallic Grey

Weight
Approx. 1.2 kg

Current Rating
6A max

Thickness
2 mm (chassis)

Capacity
Peak output up to 50W

Frequency
1 MHz to 60 MHz (model dependent)

Harmonic Suppression
> 30 dB

PCB Material
Glass epoxy FR4

Tuning Mechanism
Variable inductors and capacitors

Cooling
Passive (Heatsink), Optional fan mounting

Mounting Type
Panel/Enclosure mountable

Impedance
50 Ohms

Transistor Type
High-frequency NPN power transistors

Input Protection
Fused input

CLASS C RF TUNED AMPLIFIER Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Packaging Details
Carton Box, Export Quality also Available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001, CE

About CLASS C RF TUNED AMPLIFIER

Unlock flawless performance and take advantage of our unbeatable Promotion on CLASS C RF Tuned Amplifiers, now available at the Best price in our Clearance sale! Engineered for first-rate efficiency, these amplifiers feature invincible harmonic suppression (>30 dB), fused input protection, and a robust aluminum heatsink for passive cooling. Accommodating input ranges from 1 mW to 100 mW and delivering a peak output up to 50W, this amplifier is ideal for engineering electronics instruments. Its variable tuning mechanism, strong glass epoxy FR4 PCB, and metallic grey finish ensure reliable, panel/enclosure mounting for any lab or industrial use.

Versatile Applications & Key Advantages of CLASS C RF Tuned Amplifier

The CLASS C RF Tuned Amplifier is tailored for use in engineering electronics instruments. Highly valued for RF signal amplification, it offers the advantage of compact design, high power capacity, and fine-tuned selectivity with its adjustable inductors and capacitors. Its robust construction and IP20 rating make it reliable in engineering labs, research setups, and industrial testing environments, where first-rate RF performance is paramount.

Secure Packaging & Trusted Certifications for Every Order

Each CLASS C RF Tuned Amplifier is supplied with meticulous protective packaging to ensure flawless delivery. We offer bulk and custom supply options, making us a leading manufacturer, supplier, and exporter from India. Products are certified for industrial safety and quality. With prompt dispatch from our preferred FOB port, we ensure every order reaches clients securely and efficiently, supported by robust after-sales service.

FAQ's of CLASS C RF TUNED AMPLIFIER:

Q: How does the tuning mechanism improve the amplifier's performance?

A: The variable inductors and capacitors in the CLASS C RF Tuned Amplifier allow for precise frequency adjustments, ensuring optimal signal amplification and selectivity.

Q: What is the benefit of passive cooling with an optional fan mount?

A: Passive cooling via the heatsink provides efficient thermal dissipation, keeping the amplifier stable. For higher power demands, users can mount a fan for enhanced cooling and extended operational life.

Q: Where can the amplifier be mounted?

A: This amplifier is designed for either panel or enclosure mounting, making it versatile for various setups in engineering and laboratory environments.

Q: What applications is this amplifier most suitable for?

A: It is best used in engineering electronics instruments, making it ideal for laboratory experiments, testing setups, and RF research applications.

Q: How is the amplifier protected from input faults?

A: The amplifier features fused input protection, safeguarding internal components from electrical surges and faults to maintain flawless, safe operation.

Q: What are the packaging and export details?

A: Each unit is supplied in secure packaging, with supply and offer reliability assured. Shipping is from a leading FOB port in India, and every shipment follows industry-standard certifications.
