Chemical Fume Hood

Product Description

• Fume protection from hazards fumes generated during digestion of soil or plant with sulphuric acid in the determination of nitrogen consists of pedestal radial fan Dn200, 230v.

• Dimension:(WxDxH)mm(1200x750x2300)
• Main structure: still melamine
• Inner wall: decorated GFRC (glass fiber reinforced segment)
• Board contains non asbestos baffle plate decorated (GFRC) board contain no asbestos baffle
• Air inlet: PVC modified thermal stabilizer on top and bottom
• With top baffle damper face sash :counter balanced sliding door of temper glass
• With PVC hand rail frame
• Guide rail for sash steel enameled melamine and guide rail of 18-8 stainless steel
• Louver :molded ABS
• Water faucet :fixed goose neck faucet enameled chemical resistance with remote controlled device
• Gas cock :direct double cooked and remotes controlled cook
• Illumination :florescent lamp on camber top
• Operation panel :complete with indication lamp and two outlet receptacle for electric power ,florescent lamp switch ,indication lamp and push butane for bellower
• Base unit: cup bored with double hinged still enameled melamine.
• Extracting kit : pedestal radial faun satisfying DN200,230v. Creation proof with magnetic starter for mother for 0.25m/s face air velocity and air volume of 12cubic meatier per minute

• Cut out switch quantity 1 2m PVC extracting duct 250mm quantity 2
• Three bends PVC 250mm quantity 3
• Balancing damper 250mm quantity 1
• Brackets 200mm quantity 3
