Centrifugal Pump Test Rig

Price 500.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Centrifugal Pump Test Rig Specification

Temperature Range
Ambient to 80C

Core Components
Centrifugal Pump, Piping, Control Valves, SS Tanks, Motor

Product Type
Hydraulic

Warranty
1 year

Power Source
Electric

Automation Grade
Semi-Automatic

Accuracy
1%

Measurement Range
Flow Rate: up to 50 LPM, Head: up to 25 m

Frequency
50 Hz

Voltage
220V AC Single Phase

Feature
closed loop water circulation. compact & stand-alone set up. stainless steel tanks and wetted parts.

Capacity
1 HP or as required

Model No
Standard/Customized

Equipment Materials
Mild Steel, Stainless Steel Wetted Parts

Type
Training equipment

Usage
Laboratory, Educational Institutions

Display Type
Digital/Analog Gauge

Dimension (L*W*H)
1250 x 650 x 1200 mm (Approximate)

Weight
Approx. 70-90 kg

Centrifugal Pump Test Rig Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cheque, Telegraphic Transfer (T/T)

Sample Available
Yes

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
AS ISO 9001:2008, ISO 14001:2004 and OHSAS 18001:2007 CO.

About Centrifugal Pump Test Rig

Centrifugal Pump Test Rig

Set up consists of a centrifugal pump coupled with electrical motor, supply tank,measuring tank & pipe fittings for closed loop water circulation. Pressure and vacuum gauges are connected on delivery and suction side of pump for the purpose of measurement. The flow rate of water is measured using measuring tank and stop watch provided.

Experiments:

to determine overall efficiency and pump efficiency.
to plot head vs. Discharge, pump efficiency vs.

Features:

closed loop water circulation.
compact & stand-alone set up.
stainless steel tanks and wetted parts.
superb painted structure.
simple to operate & maintain.

Utilities required:

Electric supply.
provide 230 /- 10 vac, 50 hz, single.
earth voltage less than 5 vac. ) 5a, three pin socket with switch for pump.
Water supply.
tap water connection bsp.

Technical details:

Product centrifugal pump test rig.
Pump.
Drive.
Supply tank.
Measuring tank.
Piping.
Stop watch.
Control panel.
With required electrical instrumentation.
Electronic.
GI/ PVC.
Capacity 75 ltrs. Moc ss fitted with piezometer tube & scale.
Capacity 120 ltrs. Moc ss.
DC motor with dc drive along with non-contact type digital rpm indicator.
capacity 1 hp speed 2800 rpm (max. ), head 12m(max. ), make kirloskar.

Robust and Versatile Laboratory Training Equipment

Constructed using stainless steel tanks and wetted parts, the centrifugal pump test rig offers enhanced durability and corrosion resistance, making it ideal for continuous educational use. Its semi-automatic operation, compact footprint, and portability cater perfectly to laboratory environments, while the transparent top cover provides unobstructed observation of fluid dynamics during experiments.

Accurate Measurement and User Safety Features

Equipped with Bourdon-type pressure gauges, digital/analog display options, and precise rotameter-based flow measurement, the system delivers reliable data for comprehensive pump performance analysis. Safety is prioritized through overload protection, earthing, and MCB integration, ensuring secure operation during extended testing sessions.

Purpose-Built for Educational and Research Applications

Designed for both standard and customized models, this pump test rig is tailored for training, research, and demonstration in colleges and universities. It allows in-depth exploration of pump characteristics, efficiency, and operational principles, fostering hands-on understanding of centrifugal pump theory and practice.

FAQs of Centrifugal Pump Test Rig:

Q: How is the flow rate and head measured in the Centrifugal Pump Test Rig?

A: Flow rate is measured using a rotameter and a collecting tank with a built-in measuring scale, while head is monitored using a Bourdon-type pressure gauge. This setup ensures measurement accuracy of 1% for comprehensive pump testing.

Q: What are the main training and experimental benefits offered by this test rig?

A: The test rig enables students and researchers to visualize pump operation through the transparent top cover, analyze performance curves, and investigate parameters such as flow rate and head. Its hands-on approach enhances understanding of centrifugal pump mechanics.

Q: When should routine maintenance be performed on the rig?

A: Routine maintenance is typically recommended every semester or after every 50-100 operational hours. This includes checking the integrity of seals, cleaning tanks and piping, and inspecting the electrical safety features for reliable operation.

Q: Where is the Centrifugal Pump Test Rig most effectively used?

A: This equipment is best suited for laboratory settings in educational institutions, engineering colleges, and training centers where pump testing, fluid mechanics, or hydraulics are core topics in the curriculum.

Q: What safety provisions are integrated into the system?

A: Safety is ensured by overload protection, proper earthing, and a control panel with MCB protection. These features safeguard users against electrical hazards and operational overloads during testing.

Q: How does the closed loop water circulation system function?

A: Water is recirculated between the sump (storage) and the collecting tank, minimizing wastage and ensuring continuous operation without frequent refilling, making experiments efficient and environmentally conscious.

Q: What warranty and support are provided with the purchase?

A: The unit comes with a one-year warranty covering manufacturing defects. As an exporter and supplier in India, after-sales support and technical assistance are provided for maintenance and troubleshooting.
