CENTRIFUGAL BLOWER TEST RIG

Product Description

Specification:

CENTRIFUGAL BLOWER TEST RIG

This equipment comprises of aCentrifugal Blower coupled to a Motor.

Three interchangeable impellers withforward, backward and radial vanes are provided with the test rig. A Pitot tubeis provided in the delivery line of blower for static Power input to the DCMotor is varied by means of a Thyristor controlled DC Drive to vary the RPM ofmotor.

A RPM Indicator with Proximity sensorindicates the RPM of Blower.

Product Specification

Usage/Application: Laboratory Equipment

Variable Speed: Dc Motor with Thyristor Controlled Dc Drive

Blower: Centrifugal, Forced Draft Type

Impeller (3 Nos.): Forward Curved, Backward Curved& Radial Curved

Pilot Tube (With Manometer): For Static, Dynamic &Differential Pressure Measurement

Stop Watch: Electronic

Energy Measurement: Electronic Energy Meter, L&tMake
