Central Storage Module With Controller And Evacuated Tube Collector

Price 1000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Central Storage Module With Controller And Evacuated Tube Collector Specification

Automation Grade
Semi-Automatic

Core Components
Evacuated Tube Collector, Central Storage Tank, Controller Module, Circulation Pump, Safety Valves

Voltage
220 V AC Volt (v)

Warranty
1 Year

Accuracy
1 C (Temperature Sensor Accuracy) C

Temperature Range
30 C to 95 C Celsius (oC)

Model No
CSM-ETC200

Feature
Automatic Temperature Control, High Thermal Efficiency, Anti-corrosive Coating, Backup Electric Heater

Frequency
50 Hz Hertz (HZ)

Power Source
Solar/Electric Hybrid

Capacity
200 Liters Ltr

Measurement Range
0 C to 99 C

Equipment Materials
Stainless Steel Inner Tank, Aluminum Alloy Outer Casing

Type
Evacuated Tube Solar Water Heater with Central Storage Module

Usage
Centralized Hot Water Supply System for Domestic and Commercial Applications

Display Type
Digital LCD

Dimension (L*W*H)
1700 mm x 520 mm x 700 mm Millimeter (mm)

Weight
68 kg Kilograms (kg)

Central Storage Module With Controller And Evacuated Tube Collector Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Central Storage Module With Controller And Evacuated Tube Collector

CENTRAL STORAGE MODULE WITH CONTROLLER AND EVACUATED TUBE COLLECTOR

The system allows experiments on the generation. storage and use of heat from renewable energies. A variety of heat sources, storage types and consumers used. The system contains two different heat storage methods, piping, a pump, a driven 3-way valve and safety devices. Quick-release couplings on the Form of the module enable the hydraulic connection to evacuated tube collector.

Temperature sensors for heat storage and room temperature
Two pressure sensors for system monitoring
Flow meters and temperature sensors for determining the heat flows
Freely programmable universal controller with data logger and PC unit
Storage capacity: 150L
Number of heat exchangers: 1
Operating pressure: about. 5bar
Operating temperature: 95°C

Evacuated tube Collector :

Collector
Total area: 2,1m2
Absorbing surface: 15m2
Absorber content: 15L
Rated throughput: about 58 Uh
Safety valve: 4bar

Solar circuit station :

Solar pump: 3-stage
Safety valve: 4bar
Manometer: 0...6bar
Balancing valve: I ... I 31./min230V
I phase - PC also included
230V, 60Hz, I or 3phase Unit complete with all required accessories

Advanced Controller for Precision Oversight

The Central Storage Module incorporates a microprocessor-based digital controller, allowing users to switch between manual and automatic operation modes. The intuitive digital LCD display provides real-time monitoring of the temperature (accuracy of 1C), and makes system management straightforward, even for non-technical users. This ensures a seamless supply of hot water tailored to your preference.

Efficient Evacuated Tube Collector Technology

Equipped with 20 borosilicate glass 3.3 evacuated tubes, the system excels in capturing solar energy efficiently. The 2.4 m collector area, coupled with 50 mm polyurethane foam insulation, minimizes heat loss and ensures maximum thermal output. This advanced configuration makes it suitable for varied climates across India, guaranteeing reliable and sustainable hot water generation.

Designed for Flexibility and Longevity

Constructed with a corrosion-resistant stainless steel inner tank and an aluminum alloy outer casing, the system emphasizes durability. Its components, including a circulation pump with overload protection and safety valves, enhance reliability. The backup electric heater ensures continuous hot water availability, even on cloudy days, making this hybrid system adaptable to fluctuating weather conditions.

FAQs of Central Storage Module With Controller And Evacuated Tube Collector:

Q: How does the Central Storage Module with Evacuated Tube Collector operate?

A: This system utilizes solar energy captured by 20 evacuated borosilicate glass tubes, transferring heat to water stored in a central stainless steel tank. The microprocessor-based controller manages operations, either manually or automatically, switching to a 2000 W backup electric heater when needed, ensuring a consistent supply even during low sunlight.

Q: What are the maintenance requirements for this solar water heater system?

A: Routine maintenance involves checking the evacuated tubes for cleanliness, inspecting connections for leaks, ensuring the circulation pump and safety valves are functional, and occasionally verifying the accuracy of the digital controller display. These measures help maximize thermal efficiency and system longevity.

Q: When should I use the backup electric heater function?

A: The backup electric heater is designed for use when solar energy is insufficient, such as during consecutive cloudy or rainy days. It activates automatically or can be switched on manually via the controller, ensuring you always have access to hot water at the desired temperature.

Q: Where is the optimal installation location for this module?

A: This system is best installed on a rooftop or open terrace where it can receive unobstructed sunlight throughout the day. Secure, flat mounting ensures efficient heat absorption and system stability.

Q: What are the key benefits of the dual power source feature?

A: The hybrid solar/electric setup guarantees uninterrupted hot water supply regardless of weather conditions. Users benefit from reduced energy bills due to dominant solar heating, while the backup heater offers peace of mind during low-light periods, making the system highly reliable and cost-effective.

Q: How do I monitor system performance and adjust temperature settings?

A: System performance and temperature are displayed on the digital LCD panel. The user can manually set the desired temperature or allow the controller to adjust it automatically, depending on the chosen operating mode. Temperature sensors provide readings with 1C accuracy.

Q: What applications is this unit suitable for?

A: The CSM-ETC200 is ideal for centralized hot water supply in both domestic and commercial settings, including homes, hostels, hotels, and institutions. Its 200-liter capacity and robust construction support simultaneous usage for multiple bathrooms or kitchens.
