C B R Test Machine

Get a Price/Quote

Product Details:

Automation Grade Manual
Measurement Range 0-100 kN
Model No CBR100
Feature Durable structure Easy to operate
Power Source Manual
Capacity 100 kN
Warranty 12 months
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

C B R Test Machine Product Specifications

Model No CBR100
Type CBR Test Machine
Feature Durable structure Easy to operate
Power Source Manual
Automation Grade Manual
Weight 35 kg
Dimension (L*W*H) 500 x 300 x 800 mm
Display Type Analog gauges
Measurement Range 0-100 kN
Usage Geotechnical soil testing
Core Components Steel frame Dial gauge
Equipment Materials Steel Aluminum
Capacity 100 kN
Warranty 12 months
Accuracy High accuracy for testing

Product Description

CBR TEST MACHINE (HAND OPERATED)

We are manufacturer and exporter of civil engineering lab equipment.

Use: CBR test in Lab to determine soil bearing capacity

Standard: BS 1377, 1924, EN 13286-47, ASTM D1883, AASHTO T193

Specifications of CBR Test Machine

1 CBR Loading Press.
Proving Ring. 28 kN (6,000 lb) capacity.
Proving Ring. 50 kN (11,200 lb) capacity.
Penetration Dial Indicator. 25 mm range x 0.01 mm divisions.
4 CBR Molds.
1 Spacer Disc.
4 Filter Screens.
1 Box, Filter Paper.
2 Swell Plates.
1 Tripod Attachment.
4 Surcharge Weights.
4 Slotted Surcharge Weights.
1 Compaction Hammer.
1 Straightedge.
1 Cutting Edge.

FAQs of C B R Test Machine:

Q: What is the capacity of the CBR Test Machine Model No. CBR100?

A: The CBR Test Machine Model No. CBR100 has a capacity of 100 kN.

Q: What is the material used in the construction of the CBR Test Machine?

A: The CBR Test Machine is constructed with steel and aluminum materials.

Q: Is the CBR Test Machine CBR100 easy to operate?

A: Yes, the CBR Test Machine CBR100 features a durable structure and is easy to operate.

Q: What kind of warranty is offered with the CBR Test Machine Model No. CBR100?

A: The CBR Test Machine Model No. CBR100 comes with a 12-month warranty.

Q: What is the display type of the CBR Test Machine CBR100?

A: The CBR Test Machine CBR100 features analog gauges for display.
