AC AMMETER (RECTIFIER TYPE) 0-1,3,5..10A (WITH CURRENT TRANSFORMER)

Send Inquiry

Request To Call Back

AC AMMETER (RECTIFIER TYPE) 0-1,3,5..10A (WITH CURRENT TRANSFORMER)

Get a Price/Quote

MOQ : 1 Piece

AC AMMETER (RECTIFIER TYPE) 0-1,3,5..10A (WITH CURRENT TRANSFORMER) Specification

Features
Rugged construction, precise measurement, easy analog readability, panel mount

Components
Analog ammeter, rectifier, current transformer

Display Type
Analog needle gauge

Operating Temperature
0C to 50C

Input
AC current via current transformer

Output
Analog current reading (0-1,3,5..10A)

Power Supply
AC supply, typically sourced from measurement circuit

Sensors Specification
Current transformer (standard ratio, 10/1A for 10A full scale)

Interface
Panel mount terminals for CT input

Usage
ENGINEERING ELECTRONICS INSTRUMENTS

IP Rating
IP42 (front panel protection)

Power Source
Measuring circuit AC

Resolution
Analog scale graduation: 0.1A

Response Time
Immediate, typically <1s

Product Type
AC AMMETER (RECTIFIER TYPE) 0-1,3,5..10A (WITH CURRENT TRANSFORMER)

Application
ENGINEERING ELECTRONICS INSTRUMENTS

Rated Voltage
Typically 220V AC (depends on application)

Supply Voltage
230V AC nominal

Size
Standard panel mount, 96 x 96 mm

Dimension (L*W*H)
96 mm x 96 mm x 44 mm

Function
To measure AC current using rectification and current transformer for precision readings

Color
Black body with white analog dial and red indicator needle

Weight
Approx 250 grams

Capacity
Measures up to 10A with appropriate CT

Current Rating
0-1, 3, 5, 10A selectable via CT

Thickness
Panel thickness supported: 2-5 mm

Frequency
50-60Hz

Mounting Type
Flush panel mount with clamp

Panel Cutout Size
92mm x 92mm

Scale Material
Polycarbonate, laser-printed

Connection mode
Screw-type terminals for CT input

Case Material
ABS plastic, flame retardant

Overload Capacity
Up to 120% of Full Scale for short duration

Pointer Material
Aluminum

Dielectric Strength
2kV AC for 1 minute

Calibration
Factory calibrated

Safety Standards
Conforms to IS 1248

Accuracy
Class 1.5

Storage Temperature
-10°C to 60°C

AC AMMETER (RECTIFIER TYPE) 0-1,3,5..10A (WITH CURRENT TRANSFORMER) Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Packaging Details
Carton Box, Export Quality also Available

Main Domestic Market
All India

Certifications
ISO 9001, 14001, CE

About AC AMMETER (RECTIFIER TYPE) 0-1,3,5..10A (WITH CURRENT TRANSFORMER)

Take advantage of our distinguished Promotion and Sale on the Finest AC Ammeter (Rectifier Type) 0-1,3,5..10A, complete with a high-precision current transformer. Offered at the Best Price, this first-class analog ammeter features a flush panel mount with clamp, is factory calibrated, and delivers Class 1.5 accuracy. Its distinguished ABS flame-retardant housing ensures rugged durability, while aluminum pointer and polycarbonate laser-printed scale provide reliable readings. Conforming to IS 1248 safety standards and boasting an overload capacity up to 120%, its engineered for Engineering Electronics Instruments applications to guarantee top-tier performance.

Features, Advantages, and Application Areas

The AC Ammeter (Rectifier Type) 0-1,3,5..10A stands out with its rugged ABS case, laser-printed polycarbonate scale, and Class 1.5 accuracy. Unique competitive advantages include reliable overload capacity and immediate response time. This distinguished device is ideal for Engineering Electronics Instruments, offering accurate analog current measurement in all critical lab, testing, and industrial environments. Its panel mount system with IP42 protection ensures secure installation and longevity, while the selectable current ranges make it highly adaptable.

Packaging, Export Markets, and Port of Shipment

Upon Arrival, each AC Ammeter is safely packed in sturdy, protective packaging to guarantee product integrity at the lowest price. We cater to main export markets across Asia, Africa, and the Middle East, ensuring timely international delivery. Shipments are typically dispatched from the reputed FOB Port of Mumbai, India. Our packaging standards and export expertise ensure your instruments reach you in first-class condition, ready for immediate installation and usage.

FAQs of AC AMMETER (RECTIFIER TYPE) 0-1,3,5..10A (WITH CURRENT TRANSFORMER):

Q: How does the AC Ammeter (Rectifier Type) ensure precise current measurement?

A: The ammeter utilizes a built-in current transformer and rectifier for accurate conversion and measurement of AC current, achieving Class 1.5 accuracy, and delivering immediate analog output for reliable readings.

Q: What are the main advantages of using this distinguished AC Ammeter?

A: Key benefits include Class 1.5 measurement accuracy, robust flame-retardant ABS construction, overload capacity up to 120%, and secure flush panel mounting with easy-to-read analog display.

Q: Where can I use the AC Ammeter (Rectifier Type) 0-1,3,5..10A?

A: This instrument is perfect for Engineering Electronics Instruments applications, including test benches, control panels, laboratories, and various industrial measurement setups requiring dependable AC current monitoring.

Q: What packaging and delivery process ensures safe Arrival of the product?

A: Each ammeter is individually packed in quality, shock-absorptive material, shipped at the lowest price to minimize transit risks. Main shipments depart from Mumbai port, reaching international destinations in top condition.

Q: How is the device installed and connected for operation?

A: The ammeter is designed for flush panel mounting with a clamp, accepting CT input via screw-type terminals. The panel cutout size is 92mm x 92mm, supporting seamless installation in standard control panels.
