Gas Liquid Chromatograph

Gas Liquid Chromatograph

Product Details:

X

Product Description

GAS LIQUID CHROMATOGRAPH ( GC)
Gas Chromatograph with following detectors.
  • FID (`` Flame Ionization Detector ).
  • NPD (Nitrogen, Phosphorus Detector
Application
For analysis of pesticides Residues, Bench top, PC controlled to interface with data management system, Minimum two channel system with two columns, two injectors ( packed and Capillary) system with detector be supplied fitted.
  • Pressure (set point) 0 - 1 0 0 p s i with resolution of 0.001psi
  • Column Oven 01
  • Temp. range Up to 450C
  • Temp. programming steps / ramp 20 ramps
  • Injector System 02
  • Injection port system Split and split less
  • Option to install maximum injectors 2
  • Operating temp.(max.) 400C
  • Flow control unit
  • Maximum flow rate 0-1250 mL/ minute
  • Pressure range Upto100 psi
  • FID (Flame ionization detector) 01
  • Operating Temperature Up to 450C
  • Detection limit <1.4pg C/sec
  • Dynamic range / linearity >107
  • Data Acquisition Rate Upton 500 Hz
Accessories
  • Including sample tray, spare 1000 vials, spare ferrules, spare syringe
Data Management System Software
Foreign branded latest PC core I7 with 19 inch LED monitor and laser printer as per SSC approved specifications with preloaded licensed MS Windows XP/Vista operating system loaded with compatible software for instrument control, acquisition and data processing and report customization with backup copies, intergraded early maintenance feedback option, Intergraded method translation tool, integrated sleep & wake mode (to reduce gas and power consumption) software with the capacity to control GC through computer.
Accessories
  • All standard accessories as per manufacturers standard including operation/service manual, certificate of country of origin/guarantee of good to be supplied by the firm as brand new (one set).
  • Hydrogen Generator , generating hydrogen 99.9999% pure H2, 250 cc per hour, with spare cartridges ,
  • Hydrogen, Nitrogen, Helium Cylinders, Air Compressor, 7KVA UPS, Stabilizer, Gas supply Pipes, Filters etc. (one each)
  • Moisture Trap for Air
  • Syringe; 1L, 5L, 10L and 50L (2 each) for manual injection,
  • Auto injector syringe (10 L range) as per manufactures standard (05 each).
  • Capillary Column DB-5 ms,0.25mm x 30 x0.25m (04 Each)
  • Capillary Column DB-1 ms,0.25mm x 30 x0.25m (04 Each)
  • Septum10 pack (25pieces/pack) and Ceramic Flame Jet 10Nos.
  • Graphite Ferrules 10 packs (10 per pack)
  • Silica gel 02 packs ( 1kg/pack)
  • Empty glass columns 05 Nos. (1.2mm)
  • Tool Kit 1No.
  • Digital Thermometer with probe 01No.
  • Glass insert for capillary and packed column (05each)
  • Spare glass insert , tubing,operation manual
  • Standard test samples for checking calibration at installation.
  • Computer Branded computer compatible with software and one printer (one number).
  • Power Requirement All system operating at 220-230 V AC 50/60 Hz
  • Country of Origin USA, UK , Japan
  • Warranty Free; 01 years for parts and service.
  • Extended; 05 year for parts and service on payment.
  • Note All the accessories required for complete installation and commissioning /operation of system to be provided by the supplying firm along with onsite training of the staff.
