EM By Thomson Method Bar Magnet Method

Price 100.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

EM By Thomson Method Bar Magnet Method Specification

Resolution
Scale marking up to 0.01 units

Features
High accuracy, durable, portable design, simple operation

Response Time
Immediate

Operating Temperature
0C to 40C

Display Type
Analog meter

Usage
Physics experiments in laboratories

Components
Main unit, Bar magnet, Power cord, Galvanometer, connecting wires

Input
AC electrical input

Power Supply
AC Mains

Sensors Specification
Magnetic material sensors, internal galvanometer

Interface
Standard wire interface

Output
Measurement readings on galvanometer / scale

IP Rating
Not rated

Power Source
AC powered

Product Type
Laboratory instrument

Application
Determination of e/m ratio, magnetic field studies

Rated Voltage
220V AC

Supply Voltage
220V

Size
Standard laboratory size

Dimension (L*W*H)
330 x 220 x 120 mm

Function
Measurement of electromagnetic field strength using Thomson Method and Bar Magnet Method

Color
Blue, silver

Weight
Approx. 3.5 kg

Thickness
Magnet thickness: approx. 15 mm

Current Rating
Up to 1A

Capacity
Suitable for educational and research

Frequency
50 Hz

Bar Magnet Length
Approx. 80 mm

Insulation
High grade electrical insulation

Galvanometer Type
Moving coil

Model Number
EMT2943720

Mounting Type
Desktop

Material
Mild steel body, copper coils, high quality magnets

Environmental Standards
RoHS compliant

Packing Type
Box packaging

Cable Length
1.5 m power cord

Calibration
Factory calibrated

Finish Type
Powder coated

Safety Compliance
Meets standard lab safety regulations

EM By Thomson Method Bar Magnet Method Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Letter of Credit (L/C), Cash Advance (CA), Cash in Advance (CID), Telegraphic Transfer (T/T), Cheque

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Eastern Europe, Middle East, Western Europe, Asia, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About EM By Thomson Method Bar Magnet Method

E M By Thomson Method Bar Magnet Method :

Objective:-

To study charge of an electron using Thomson Method.

Features:-

High Voltage Power Supply with one Meter Provided to measure the Deflection Voltage.Complete with intensity,Focus & Deflection controls.
It is provided with accessories such as compass box,set of ELICO magnets,Teak wood stand with CRT mounted,Teak wood U stand with scale on both theorems for placing magnets.

Advanced Field Measurement for Physics Labs

Designed for educational and research environments, the EM By Thomson Method Bar Magnet Method provides precise measurements of electromagnetic field strength and is essential for studies related to the e/m ratio and magnetic fields. Its robust construction, portable design, and immediate response time make it highly suitable for frequent laboratory use.

Reliable Construction & Superior Safety Features

Featuring a mild steel body, copper coils, and high-quality insulation, this device ensures long-term durability and operational safety. The factory calibration and RoHS compliance validate its suitability for academic and professional setups. Powder coating and standard lab safety regulations further enhance its reliability.

FAQs of EM By Thomson Method Bar Magnet Method:

Q: How do you operate the EM By Thomson Method Bar Magnet Method?

A: Simply connect the power cord to a 220V AC mains supply, position the bar magnet on the supplied desktop mount, and use the connecting wires to link the galvanometer. Measurements can then be taken via the analog scale with immediate response time.

Q: What is the primary usage of this instrument in laboratories?

A: This device is primarily used to measure electromagnetic field strength through Thomson and Bar Magnet Methods, ideal for determining the e/m ratio and conducting magnetic field studies in physics laboratories.

Q: When should calibration be performed on this device?

A: The instrument is factory calibrated prior to delivery, ensuring immediate accuracy upon first use. No additional calibration is required before initial operation unless long-term or intensive usage necessitates re-calibration.

Q: Where is this equipment most commonly installed or used?

A: The EM By Thomson Method Bar Magnet Method is intended for desktop use in academic, educational, and research laboratory settings, providing reliable results for physics experiments.

Q: What is the process for measuring electromagnetic field strength with this product?

A: Install the instrument on a desktop, connect the bar magnet and galvanometer as instructed, energize via the AC mains, and observe galvanometer readings as you conduct experiments with varied magnetic field setups and configurations.

Q: What are the key benefits of using this model in laboratory experiments?

A: Key benefits include high measurement accuracy, durable construction, safety compliance, immediate response readings, easy portability, and user-friendly operationmaking it especially effective for teaching and research applications.
